Toz Keçeleri
K09
Toz Keçesi
- Malzeme
- PU NBR
- Kodu
- PU9201 NB9001
- Sıcaklık (max) °C
- -40/+100 -30/+105
- Kayma Hızı (max)- m/s
- 1.0
Avantajları
- Üstün sıyırma özelliği
- Basit kanal tasarımı
- Kanal içinde dönmeme özelliği
- Poliüretan malzemenin yüksek yırtılma ve kopma mukavemeti sayesinde ağır şartlarda kullanıma uygun olması
- Kolay montaj yapılabilmesi
Uygulama Alanları
- Tarım sektörü
- İş makineleri sektörü
- Vinçler
- Forkliftler
- Genel endüstriyel silindirler
- Maden sektörü
Teknik Çizim
Ölçü Tablosu
149 ölçü · Kod veya ölçü ile filtreleyin
149 sonuç
| Kod | d (f8) | D (H10) | D1 (H10) | L (+0.2/-0) | L1 (+0.2/-0) | H | MALZEME | KASTAŞ KOD | |
|---|---|---|---|---|---|---|---|---|---|
| K09-003 | 3 | 7 | 6 | 2.2 | 3.2 | 4 | NB9001 | 10001501 | — |
| K09-004 | 4 | 12 | 10 | 4 | 5 | 7 | NB9001 | 10001502 | — |
| K09-005 | 5 | 8 | 7 | 2.2 | 3.2 | 4 | NB9001 | 10001503 | — |
| K09-006 | 6 | 10 | 9 | 2.2 | 3.2 | 4 | NB9001 | 10001505 | — |
| K09-006 PU | 6 | 10 | 9 | 2.2 | 3.2 | 4 | PU9201 | 10001507 | — |
| K09-008 | 8 | 16 | 14 | 4 | 5 | 7 | NB9001 | 10001508 | — |
| K09-008 PU | 8 | 16 | 14 | 4 | 5 | 7 | PU9201 | 10001510 | — |
| K09-010 | 10 | 18 | 16 | 4 | 5 | 7 | NB9001 | 10001512 | — |
| K09-010 PU | 10 | 18 | 16 | 4 | 5 | 7 | PU9201 | 10001514 | — |
| K09-012 | 12 | 20 | 18 | 4 | 5 | 7 | NB9001 | 10001516 | — |
| K09-012 PU | 12 | 20 | 18 | 4 | 5 | 7 | PU9201 | 10001518 | — |
| K09-012/2 | 12 | 18 | 16 | 2.6 | 3.6 | 5 | NB9001 | 10001519 | — |
| K09-012/2 PU | 12 | 18 | 16 | 2.6 | 3.6 | 5 | PU9201 | 10001521 | — |
| K09-014 | 14 | 22 | 20 | 4 | 5 | 7 | NB9001 | 10001525 | — |
| K09-014 PU | 14 | 22 | 20 | 4 | 5 | 7 | PU9201 | 10001527 | — |
| K09-014/1 PU | 14 | 20 | 18 | 2.6 | 3.6 | 5 | PU9201 | 10001528 | — |
| K09-014/2 | 14 | 20 | 18 | 3.1 | 4.1 | 5 | NB9001 | 10001529 | — |
| K09-015 | 15 | 23 | 21 | 4 | 5 | 7 | NB9001 | 10001531 | — |
| K09-015 PU | 15 | 23 | 21 | 4 | 5 | 7 | PU9201 | 10001533 | — |
| K09-016 | 16 | 24 | 22 | 4 | 5 | 7 | NB9001 | 10001534 | — |
| K09-016 PU | 16 | 24 | 22 | 4 | 5 | 7 | PU9201 | 10001536 | — |
| K09-016/1 | 16 | 22 | 20 | 3.1 | 4.1 | 5 | NB9001 | 10001537 | — |
| K09-017 | 17 | 25 | 23 | 4 | 5 | 7 | NB9001 | 10001538 | — |
| K09-018 | 18 | 26 | 24 | 4 | 5 | 7 | NB9001 | 10001540 | — |
| K09-018 PU | 18 | 26 | 24 | 4 | 5 | 7 | PU9201 | 10001542 | — |
| K09-020 | 20 | 28 | 26 | 4 | 5 | 7 | NB9001 | 10001544 | — |
| K09-020 PU | 20 | 28 | 26 | 4 | 5 | 7 | PU9201 | 10001546 | — |
| K09-022 | 22 | 30 | 28 | 4 | 5 | 7 | NB9001 | 10001549 | — |
| K09-022 PU | 22 | 30 | 28 | 4 | 5 | 7 | PU9201 | 10001551 | — |
| K09-022/1 | 22 | 32 | 30 | 4 | 5 | 7 | NB9001 | 10001554 | — |
| K09-022/2 | 22 | 28 | 26 | 3.1 | 4.1 | 5 | NB9001 | 10001555 | — |
| K09-023 | 23 | 31 | 29 | 4 | 5 | 7 | NB9001 | 10001557 | — |
| K09-024 | 24 | 32 | 30 | 4 | 5 | 7 | NB9001 | 10001558 | — |
| K09-024 PU | 24 | 32 | 30 | 4 | 5 | 7 | PU9201 | 10001560 | — |
| K09-025 | 25 | 33 | 31 | 4 | 5 | 7 | NB9001 | 10001562 | — |
| K09-025 PU | 25 | 33 | 31 | 4 | 5 | 7 | PU9201 | 10001564 | — |
| K09-025/1 | 25 | 35 | 33 | 4 | 5 | 7 | NB9001 | 10001566 | — |
| K09-025/1 PU | 25 | 35 | 33 | 4 | 5 | 7 | PU9201 | 10001568 | — |
| K09-025/2 | 25 | 34 | 32 | 5.5 | 6.5 | 8.5 | NB9001 | 10001569 | — |
| K09-025/2 PU | 25 | 34 | 32 | 5.5 | 6.5 | 8.5 | PU9201 | 10001570 | — |
| K09-026 | 26 | 34 | 32 | 4 | 5 | 7 | NB9001 | 10001572 | — |
| K09-026 PU | 26 | 34 | 32 | 4 | 5 | 7 | PU9201 | 10001574 | — |
| K09-028 | 28 | 36 | 34 | 4 | 5 | 7 | NB9001 | 10001575 | — |
| K09-028 PU | 28 | 36 | 34 | 4 | 5 | 7 | PU9201 | 10001577 | — |
| K09-030 | 30 | 38 | 36 | 4 | 5 | 7 | NB9001 | 10001581 | — |
| K09-030 PU | 30 | 38 | 36 | 4 | 5 | 7 | PU9201 | 10001583 | — |
| K09-030/1 | 30 | 40 | 38 | 4 | 5 | 7 | NB9001 | 10001584 | — |
| K09-030/2 | 30 | 36 | 34 | 3.1 | 4.1 | 5 | NB9001 | 10001585 | — |
| K09-032 | 32 | 40 | 38 | 4 | 5 | 7 | NB9001 | 10001587 | — |
| K09-032 PU | 32 | 40 | 38 | 4 | 5 | 7 | PU9201 | 10001589 | — |
| K09-033 | 33 | 41 | 39 | 4 | 5 | 7 | NB9001 | 10001590 | — |
| K09-034 | 34 | 42 | 40 | 4 | 5 | 7 | NB9001 | 10001591 | — |
| K09-034 PU | 34 | 42 | 40 | 4 | 5 | 7 | PU9201 | 10001593 | — |
| K09-035 | 35 | 43 | 41 | 4 | 5 | 7 | NB9001 | 10001594 | — |
| K09-035 PU | 35 | 43 | 41 | 4 | 5 | 7 | PU9201 | 10001596 | — |
| K09-035/1 | 35 | 45 | 43 | 4 | 5 | 7 | NB9001 | 10001597 | — |
| K09-035/1 PU | 35 | 45 | 43 | 4 | 5 | 7 | PU9201 | 10001599 | — |
| K09-036 | 36 | 44 | 42 | 4 | 5 | 7 | NB9001 | 10001600 | — |
| K09-036 PU | 36 | 44 | 42 | 4 | 5 | 7 | PU9201 | 10001602 | — |
| K09-036/1 | 36 | 42 | 41 | 3.1 | 4.1 | 5 | NB9001 | 10001603 | — |
| K09-036/1 PU | 36 | 42 | 41 | 3.1 | 4.1 | 5 | PU9201 | 10001605 | — |
| K09-038 | 38 | 46 | 44 | 4 | 5 | 7 | NB9001 | 10001607 | — |
| K09-038 PU | 38 | 46 | 44 | 4 | 5 | 7 | PU9201 | 10001609 | — |
| K09-040 | 40 | 48 | 46 | 4 | 5 | 7 | NB9001 | 10001610 | — |
| K09-040 PU | 40 | 48 | 46 | 4 | 5 | 7 | PU9201 | 10001612 | — |
| K09-040/1 | 40 | 50 | 48 | 4 | 5 | 7 | NB9001 | 10001615 | — |
| K09-042 | 42 | 50 | 48 | 4 | 5 | 7 | NB9001 | 10001617 | — |
| K09-042 PU | 42 | 50 | 48 | 4 | 5 | 7 | PU9201 | 10001618 | — |
| K09-044 | 44 | 52 | 50 | 4 | 5 | 7 | NB9001 | 10001619 | — |
| K09-045 | 45 | 53 | 51 | 4 | 5 | 7 | NB9001 | 10001620 | — |
| K09-045 PU | 45 | 53 | 51 | 4 | 5 | 7 | PU9201 | 10001623 | — |
| K09-045/1 | 45 | 56 | 54 | 5 | 6 | 8 | NB9001 | 10001626 | — |
| K09-048 | 48 | 56 | 54 | 4 | 5 | 7 | NB9001 | 10001627 | — |
| K09-048 PU | 48 | 56 | 54 | 4 | 5 | 7 | PU9201 | 10001629 | — |
| K09-050 | 50 | 58 | 56 | 4 | 5 | 7 | NB9001 | 10001630 | — |
| K09-050 PU | 50 | 58 | 56 | 4 | 5 | 7 | PU9201 | 10001633 | — |
| K09-050/1 | 50 | 62 | 59 | 5.5 | 7 | 10 | NB9001 | 10001636 | — |
| K09-050/1 PU | 50 | 62 | 59 | 5.5 | 7 | 10 | PU9201 | 10001637 | — |
| K09-052 | 52 | 60 | 58 | 4 | 5 | 7 | NB9001 | 10001638 | — |
| K09-052 PU | 52 | 60 | 58 | 4 | 5 | 7 | PU9201 | 10001639 | — |
| K09-054 | 54 | 62 | 60 | 4 | 5 | 7 | NB9001 | 10001640 | — |
| K09-054 PU | 54 | 62 | 60 | 4 | 5 | 7 | PU9201 | 10001641 | — |
| K09-055 | 55 | 63 | 61 | 4 | 5 | 7 | NB9001 | 10001642 | — |
| K09-055 PU | 55 | 63 | 61 | 4 | 5 | 7 | PU9201 | 10001644 | — |
| K09-056 | 56 | 64 | 62 | 4 | 5 | 7 | NB9001 | 10001645 | — |
| K09-056 PU | 56 | 64 | 62 | 4 | 5 | 7 | PU9201 | 10001649 | — |
| K09-057 | 57 | 65 | 63 | 4 | 5 | 7 | NB9001 | 10001650 | — |
| K09-057 PU | 57 | 65 | 63 | 4 | 5 | 7 | PU9201 | 10001651 | — |
| K09-060 | 60 | 68 | 66 | 4 | 5 | 7 | NB9001 | 10001652 | — |
| K09-060 PU | 60 | 68 | 66 | 4 | 5 | 7 | PU9201 | 10001654 | — |
| K09-060/1 | 60 | 72 | 66.8 | 5.5 | 7 | 10 | NB9001 | 10001656 | — |
| K09-062 | 62 | 70 | 68 | 4 | 5 | 7 | NB9001 | 10001657 | — |
| K09-063 | 63 | 71 | 69 | 4 | 5 | 7 | NB9001 | 10001659 | — |
| K09-063 PU | 63 | 71 | 69 | 4 | 5 | 7 | PU9201 | 10001661 | — |
| K09-065 | 65 | 73 | 71 | 4 | 5 | 7 | NB9001 | 10001662 | — |
| K09-065 PU | 65 | 73 | 71 | 4 | 5 | 7 | PU9201 | 10001664 | — |
| K09-068 | 68 | 76 | 74 | 4 | 5 | 7 | NB9001 | 10001666 | — |
| K09-070 | 70 | 78 | 76 | 4 | 5 | 7 | NB9001 | 10001668 | — |
| K09-070 PU | 70 | 78 | 76 | 4 | 5 | 7 | PU9201 | 10001670 | — |
| K09-075 | 75 | 83 | 81 | 4 | 5 | 7 | NB9001 | 10001672 | — |
| K09-075 PU | 75 | 83 | 81 | 4 | 5 | 7 | PU9201 | 10001674 | — |
| K09-078 | 78 | 86 | 84 | 4 | 5 | 7 | NB9001 | 10001676 | — |
| K09-080 | 80 | 88 | 86 | 4 | 5 | 7 | NB9001 | 10001678 | — |
| K09-080 PU | 80 | 88 | 86 | 4 | 5 | 7 | PU9201 | 10001680 | — |
| K09-085 | 85 | 93 | 91 | 4 | 5 | 7 | NB9001 | 10001681 | — |
| K09-085 PU | 85 | 93 | 91 | 4 | 5 | 7 | PU9201 | 10001683 | — |
| K09-088 | 88 | 96 | 91 | 4 | 5 | 7 | NB9001 | 10001684 | — |
| K09-090 | 90 | 98 | 96 | 4 | 5 | 7 | NB9001 | 10001685 | — |
| K09-090 PU | 90 | 98 | 96 | 4 | 5 | 7 | PU9201 | 10001687 | — |
| K09-092 | 92 | 100 | 98 | 4 | 5 | 7 | NB9001 | 10001689 | — |
| K09-095 | 95 | 103 | 101 | 4 | 5 | 7 | NB9001 | 10001690 | — |
| K09-095 PU | 95 | 103 | 101 | 4 | 5 | 7 | PU9201 | 10001691 | — |
| K09-100 | 100 | 108 | 106 | 4 | 5 | 7 | NB9001 | 10001692 | — |
| K09-100 PU | 100 | 108 | 106 | 4 | 5 | 7 | PU9201 | 10001694 | — |
| K09-102 | 102 | 114 | 111 | 5.5 | 7 | 10 | NB9001 | 10001695 | — |
| K09-106 PU | 106 | 118 | 115 | 5 | 6.5 | 10 | PU9201 | 10001696 | — |
| K09-110 | 110 | 118 | 116 | 4 | 5 | 7 | NB9001 | 10001697 | — |
| K09-110/1 | 110 | 122 | 119 | 5.5 | 7 | 10 | NB9001 | 10001700 | — |
| K09-110/1 PU | 110 | 122 | 119 | 5.5 | 7 | 10 | PU9201 | 10001701 | — |
| K09-115 | 115 | 127 | 124 | 5.5 | 7 | 10 | NB9001 | 10001702 | — |
| K09-115 PU | 115 | 127 | 124 | 5.5 | 7 | 10 | PU9201 | 10001703 | — |
| K09-117/1 PU | 117 | 129 | 126 | 5 | 6.5 | 10 | PU9201 | 10001706 | — |
| K09-120 | 120 | 132 | 129 | 5.5 | 7 | 10 | NB9001 | 10001707 | — |
| K09-120 PU | 120 | 132 | 129 | 5.5 | 7 | 10 | PU9201 | 10001708 | — |
| K09-125 | 125 | 137 | 134 | 5.5 | 7 | 10 | NB9001 | 10001709 | — |
| K09-128 | 128 | 140 | 137 | 5.5 | 7 | 10 | NB9001 | 10001711 | — |
| K09-130 | 130 | 142 | 139 | 5.5 | 7 | 10 | NB9001 | 10001712 | — |
| K09-130 PU | 130 | 142 | 139 | 5.5 | 7 | 10 | PU9201 | 10001713 | — |
| K09-135 | 135 | 147 | 144 | 5.5 | 7 | 10 | NB9001 | 10001714 | — |
| K09-135 PU | 135 | 147 | 144 | 5.5 | 7 | 10 | PU9201 | 10001715 | — |
| K09-140 | 140 | 152 | 149 | 5.5 | 7 | 10 | NB9001 | 10001717 | — |
| K09-148 PU | 148 | 156 | 154 | 4 | 5 | 7 | PU9201 | 10001719 | — |
| K09-150 | 150 | 162 | 159 | 5.5 | 7 | 10 | NB9001 | 10001720 | — |
| K09-150 PU | 150 | 162 | 159 | 5.5 | 7 | 10 | PU9201 | 10001721 | — |
| K09-152 | 152 | 164 | 161 | 5.5 | 7 | 10 | NB9001 | 10001722 | — |
| K09-155 | 155 | 167 | 164 | 5.5 | 7 | 10 | NB9001 | 10001723 | — |
| K09-155 PU | 155 | 167 | 164 | 5.5 | 7 | 10 | PU9201 | 10001724 | — |
| K09-160 | 160 | 172 | 169 | 5.5 | 7 | 10 | NB9001 | 10001725 | — |
| K09-160 PU | 160 | 172 | 169 | 5.5 | 7 | 10 | PU9201 | 10001726 | — |
| K09-165 | 165 | 177 | 174 | 5.5 | 7 | 10 | NB9001 | 10001728 | — |
| K09-175 PU | 175 | 187 | 184 | 5.5 | 7 | 10 | PU9201 | 10001730 | — |
| K09-180 | 180 | 192 | 189 | 5.5 | 7 | 10 | NB9001 | 10001731 | — |
| K09-180 PU | 180 | 192 | 189 | 5.5 | 7 | 10 | PU9201 | 10001732 | — |
| K09-190 | 190 | 202 | 199 | 5.5 | 7 | 10 | NB9001 | 10001733 | — |
| K09-200 | 200 | 212 | 209 | 5.5 | 7 | 10 | NB9001 | 10001734 | — |
| K09-210 | 210 | 225 | 222 | 6.5 | 8 | 13 | NB9001 | 10001736 | — |
| K09-210/1 | 210 | 218 | 216 | 4 | 5 | 7 | NB9001 | 10001737 | — |
| K09-220 | 220 | 235 | 232 | 6.5 | 8 | 13 | NB9001 | 10001738 | — |
| K09-250 | 250 | 265 | 262 | 6.5 | 8 | 13 | NB9001 | 10001740 | — |
