Diğer Sızdırmazlık Elemanları
K150
V Manşet Ring
- Malzeme
- BEZLİ NBR
- Kodu
- FB8502
- Basınç (max) bar
- 250
- Sıcaklık (max) °C
- -30/+80
- Kayma Hızı (max)- m/s
- 2.0
Avantajları
- Yüksek hız dayanımı
- Suda çalışabilmesi
- Su-yağ karışımlarında çalışabilmesi
- Uzun kullanım süresi
- Kanal ölçüsünün ayarlanabilir olması
Uygulama Alanları
- Maden sektörü
- Yüksek basınçlı yıkama makineleri sektörü
Teknik Çizim
Ölçü Tablosu
37 ölçü · Kod veya ölçü ile filtreleyin
37 sonuç
| Kod | d (f7) | D (H9) | H | H1 | C | MALZEME | KASTAŞ KOD | |
|---|---|---|---|---|---|---|---|---|
| K150-024 | 15 | 24 | 3 | 5 | 6 | FB8502 | 10002362 | — |
| K150-025 | 15 | 25 | 3 | 5 | 6 | FB8502 | 10002363 | — |
| K150-026 | 18 | 26 | 3 | 5 | 6 | FB8502 | 10002365 | — |
| K150-028 | 15 | 28 | 4 | 6.5 | 7 | FB8502 | 10002368 | — |
| K150-028/1 | 18 | 28 | 3.5 | 5.5 | 6 | FB8502 | 10002370 | — |
| K150-028/2 | 18 | 28 | 4 | 6 | 6 | FB8502 | 10002371 | — |
| K150-030 | 15 | 30 | 4.5 | 7.5 | 8 | FB8502 | 10002372 | — |
| K150-030/1 | 16 | 30 | 4 | 7 | 8 | FB8502 | 10002373 | — |
| K150-030/2 | 18 | 30 | 3.5 | 6 | 7 | FB8502 | 10002374 | — |
| K150-030/3 | 20 | 30 | 3.3 | 5.5 | 6 | FB8502 | 10002376 | — |
| K150-032 | 18 | 32 | 4.6 | 7.1 | 8 | FB8502 | 10002378 | — |
| K150-032/1 | 20 | 32 | 4.5 | 6.7 | 7 | FB8502 | 10002379 | — |
| K150-032/2 | 22 | 32 | 3.3 | 5.7 | 6 | FB8502 | 10002380 | — |
| K150-034 | 18 | 34 | 4 | 6 | 8 | FB8502 | 10002381 | — |
| K150-034/1 | 20 | 34 | 4.5 | 7.5 | 8 | FB8502 | 10002382 | — |
| K150-035 | 20 | 35 | 4.5 | 7.5 | 8 | FB8502 | 10002383 | — |
| K150-035/1 | 22 | 35 | 4.5 | 7 | 7 | FB8502 | 10002384 | — |
| K150-035/2 | 24 | 35 | 4 | 6 | 7 | FB8502 | 10002385 | — |
| K150-035/3 | 25 | 35 | 3.3 | 5.5 | 6 | FB8502 | 10002386 | — |
| K150-037 | 25 | 37 | 3.6 | 6.7 | 7 | FB8502 | 10002387 | — |
| K150-037/1 | 20 | 37 | 4.5 | 7.5 | 9 | FB8502 | 10002388 | — |
| K150-038 | 22 | 38 | 3.5 | 8.5 | 8 | FB8502 | 10002389 | — |
| K150-038/1 | 25 | 38 | 4.6 | 7 | 7 | FB8502 | 10002390 | — |
| K150-038/2 | 28 | 38 | 4.1 | 6.1 | 6 | FB8502 | 10002391 | — |
| K150-045 | 30 | 45 | 4.5 | 7.5 | 8 | FB8502 | 10002392 | — |
| K150-048 | 36 | 48 | 3.5 | 6 | 7 | FB8502 | 10002393 | — |
| K150-048/1 | 38 | 48 | 3.5 | 6 | 6 | FB8502 | 10002394 | — |
| K150-050/1 | 40 | 50 | 3.5 | 6 | 6 | FB8502 | 10002399 | — |
| K150-055 | 40 | 55 | 4.5 | 7.5 | 8 | FB8502 | 10002401 | — |
| K150-056 | 36 | 56 | 6 | 10 | 9 | FB8502 | 10002403 | — |
| K150-060 | 45 | 60 | 4.5 | 7.5 | 8 | FB8502 | 10002405 | — |
| K150-060/1 | 50 | 60 | 3.5 | 5.5 | 6 | FB8502 | 10002406 | — |
| K150-065 | 50 | 65 | 4.5 | 7.5 | 8 | FB8502 | 10002407 | — |
| K150-065/1 | 55 | 65 | 3.5 | 5.5 | 6 | FB8502 | 10002408 | — |
| K150-070 | 55 | 70 | 4.5 | 7.5 | 8 | FB8502 | 10002409 | — |
| K150-076 | 60 | 76 | 5 | 8 | 8 | FB8502 | 10002410 | — |
| K150-080 | 65 | 80 | 4.5 | 7.5 | 8 | FB8502 | 10002411 | — |
