Döner Mil Keçeleri
K752
Piston Keçesi
- Malzeme
- PTFE NBR
- Kodu
- PT6003 NB7001
- Basınç (max) bar
- 300
- Sıcaklık (max) °C
- -30/+105
- Kayma Hızı (max)- m/s
- 5
Avantajları
- Yüksek aşınma dayanımı
- Düşük sürtünme, yüzeye yapışmama özelliği
- Yüksek statik ve dinamik sızdırmazlık
- Tasarımında bulunan yağlama kanalları ile uzun hizmet ömrü
- Yüksek akma dayanımı
- O-ring malzemesine bağlı olarak kimyasallara ve sıcaklığa karşı yüksek dayanımı
Uygulama Alanları
- Döner kule sistemleri
- Döner bağlantı elemanları
- Hidrolik dağıtıcılar
- Araç üstü sektörü
Teknik Çizim
Ölçü Tablosu
52 ölçü · Kod veya ölçü ile filtreleyin
Akma boşluğu (S) tablosu için tıklayınız
52sonuç
| Kod | D (H8) | d (h9) | L (+0.2/-0) | r | C | O-Ring | MALZEME | KASTAŞ KOD | |
|---|---|---|---|---|---|---|---|---|---|
| K752-015 | 15 | 10.1 | 2.2 | 0.4 | 3 | 9.75x1.78 | PT6003 | 10028252 | — |
| K752-016 | 16 | 11.1 | 2.2 | 0.4 | 3 | 10.82x1.78 | PT6003 | 10028253 | — |
| K752-020 | 20 | 15.1 | 2.2 | 0.4 | 3 | 15.20x1.78 | PT6003 | 10028254 | — |
| K752-025 | 25 | 20.1 | 2.2 | 0.4 | 3 | 19.00x1.78 | PT6003 | 10028255 | — |
| K752-028 | 28 | 20.5 | 3.2 | 0.6 | 4.5 | 20.29x2.62 | PT6003 | 10028256 | — |
| K752-030 | 30 | 25.1 | 2.2 | 0.4 | 3 | 25.12x1.78 | PT6003 | 10028257 | — |
| K752-032 | 32 | 27.1 | 2.2 | 0.4 | 3 | 26.70x1.78 | PT6003 | 10028258 | — |
| K752-032/1 | 32 | 24.5 | 3.2 | 0.6 | 4.5 | 23.81x2.62 | PT6003 | 10028260 | — |
| K752-035 | 35 | 30.1 | 2.2 | 0.4 | 3 | 29.87x1.78 | PT6003 | 10028261 | — |
| K752-040 | 40 | 32.5 | 3.2 | 0.6 | 4.5 | 31.42x2.62 | PT6003 | 10028264 | — |
| K752-040/1 | 40 | 29 | 4.2 | 0.8 | 5.5 | 28.17x3.53 | PT6003 | 10028266 | — |
| K752-045 | 45 | 37.5 | 3.2 | 0.6 | 4.5 | 36.17x2.62 | PT6003 | 10028268 | — |
| K752-050 | 50 | 42.5 | 3.2 | 0.6 | 4.5 | 42.52x2.62 | PT6003 | 10028270 | — |
| K752-052 | 52 | 44.5 | 3.2 | 0.6 | 4.5 | 44.12x2.62 | PT6003 | 10028273 | — |
| K752-055 | 55 | 47.5 | 3.2 | 0.6 | 4.5 | 47.29x2.62 | PT6003 | 10028275 | — |
| K752-060 | 60 | 52.5 | 3.2 | 0.6 | 4.5 | 52.07x2.62 | PT6003 | 10028276 | — |
| K752-063 | 63 | 55.5 | 3.2 | 0.6 | 4.5 | 53.65x2.62 | PT6003 | 10028278 | — |
| K752-065 | 65 | 57.5 | 3.2 | 0.6 | 4.5 | 56.82x2.62 | PT6003 | 10028280 | — |
| K752-070 | 70 | 62.5 | 3.2 | 0.6 | 4.5 | 61.60x2.62 | PT6003 | 10028282 | — |
| K752-075 | 75 | 67.5 | 3.2 | 0.6 | 4.5 | 66.35x2.62 | PT6003 | 10028285 | — |
| K752-080 | 80 | 69 | 4.2 | 0.8 | 5.5 | 68.26x3.53 | PT6003 | 10028286 | — |
| K752-080/1 | 80 | 64.5 | 6.3 | 1.2 | 6 | 62.87x5.33 | PT6003 | 10028287 | — |
| K752-085 | 85 | 74 | 4.2 | 0.8 | 5.5 | 73.03x3.53 | PT6003 | 10028289 | — |
| K752-090 | 90 | 79 | 4.2 | 0.8 | 5.5 | 78.97x3.53 | PT6003 | 10028290 | — |
| K752-095 | 95 | 84 | 4.2 | 0.8 | 5.5 | 82.14x3.53 | PT6003 | 10028291 | — |
| K752-100 | 100 | 89 | 4.2 | 0.8 | 5.5 | 88.50x3.53 | PT6003 | 10028292 | — |
| K752-105 | 105 | 94 | 4.2 | 0.8 | 5.5 | 91.67x3.53 | PT6003 | 10028294 | — |
| K752-110 | 110 | 99 | 4.2 | 0.8 | 5.5 | 98.02x3.53 | PT6003 | 10028295 | — |
| K752-115 | 115 | 104 | 4.2 | 0.8 | 5.5 | 101.20x3.53 | PT6003 | 10028297 | — |
| K752-120 | 120 | 109 | 4.2 | 0.8 | 5.5 | 107.54x3.53 | PT6003 | 10028299 | — |
| K752-125 | 125 | 114 | 4.2 | 0.8 | 5.5 | 113.90x3.53 | PT6003 | 10028300 | — |
| K752-130 | 130 | 119 | 4.2 | 0.8 | 5.5 | 117.07x3.53 | PT6003 | 10028301 | — |
| K752-135 | 135 | 119.5 | 6.3 | 1.2 | 6 | 117.48x5.33 | PT6003 | 10028302 | — |
| K752-135/1 | 135 | 124 | 4.2 | 0.8 | 5.5 | 120.25x3.53 | PT6003 | 10028303 | — |
| K752-140 | 140 | 124.5 | 6.3 | 1.2 | 6 | 123.80x5.33 | PT6003 | 10028304 | — |
| K752-145 | 145 | 134 | 4.2 | 0.8 | 5.5 | 132.94x3.53 | PT6003 | 10028305 | — |
| K752-150 | 150 | 134.5 | 6.3 | 1.2 | 6 | 133.35x5.33 | PT6003 | 10028306 | — |
| K752-155 | 155 | 144 | 4.2 | 0.8 | 5.5 | 142.47x3.53 | PT6003 | 10028308 | — |
| K752-160 | 160 | 144.5 | 6.3 | 1.2 | 6 | 142.24x5.33 | PT6003 | 10028309 | — |
| K752-170 | 170 | 154.5 | 6.3 | 1.2 | 6 | 151.77x5.33 | PT6003 | 10028310 | — |
| K752-175 | 175 | 159.5 | 6.3 | 1.2 | 6 | 155.00x5.33 | PT6003 | 10028311 | — |
| K752-180 | 180 | 164.5 | 6.3 | 1.2 | 6 | 161.30x5.33 | PT6003 | 10028312 | — |
| K752-190 | 190 | 174.5 | 6.3 | 1.2 | 6 | 170.82x5.33 | PT6003 | 10028314 | — |
| K752-200 | 200 | 184.5 | 6.3 | 1.2 | 6 | 183.52x5.33 | PT6003 | 10028315 | — |
| K752-210 | 210 | 194.5 | 6.3 | 1.2 | 6 | 189.87x5.33 | PT6003 | 10028318 | — |
| K752-220 | 220 | 204.5 | 6.3 | 1.2 | 6 | 202.57x5.33 | PT6003 | 10028321 | — |
| K752-230 | 230 | 214.5 | 6.3 | 1.2 | 6 | 208.92x5.33 | PT6003 | 10028322 | — |
| K752-240 | 240 | 224.5 | 6.3 | 1.2 | 6 | 221.62x5.33 | PT6003 | 10028323 | — |
| K752-250 | 250 | 234.5 | 6.3 | 1.2 | 6 | 234.32x5.33 | PT6003 | 10028324 | — |
| K752-260 | 260 | 244.5 | 6.3 | 1.2 | 6 | 247.02x5.33 | PT6003 | 10028326 | — |
| K752-280 | 280 | 264.5 | 6.3 | 1.2 | 6 | 266.07x5.33 | PT6003 | 10028327 | — |
| K752-300 | 300 | 284.5 | 6.3 | 1.2 | 6 | 278.77x5.33 | PT6003 | 10028329 | — |
