Hidrolik Boğaz Sızdırmazlık Elemanları
XT200
Yüksek Dayanımlı Boğaz Keçesi
- Malzeme
- PU
- Kodu
- PU9414
- Basınç (max) bar
- 400
- Sıcaklık (max) °C
- -35/+125
- Kayma Hızı (max)- m/s
- 0.5
Avantajları
- Üstün statik ve dinamik sızdırmazlık özelliği
- Uzun hizmet ömrü
- İnce yağ filmi kalınlığı
- Yüksek akma dayanımı
Uygulama Alanları
- İş makineleri sektörü
- Liftler
- Enjeksiyon tezgahları
- Forkliftler
- Araç üstü sektörü
- Tarım sektörü
Teknik Çizim
Ölçü Tablosu
119 ölçü · Kod veya ölçü ile filtreleyin
Akma boşluğu (S) tablosu için tıklayınız
119sonuç
| Kod | d (f8) | D (H10) | L (+0.2/-0) | H | KASTAŞ KOD | |
|---|---|---|---|---|---|---|
| XT200-018 | 18 | 24 | 5.2 | 4.7 | 10035514 | indir |
| XT200-020 | 20 | 28 | 6.3 | 5.7 | 10054125 | indir |
| XT200-020/1 | 20 | 30 | 7 | 6.3 | 10054131 | indir |
| XT200-020/2 | 20 | 30 | 9 | 8 | 10054133 | indir |
| XT200-022 | 22 | 30 | 6.3 | 5.7 | 10043977 | indir |
| XT200-025 | 25 | 33 | 6.3 | 5.7 | 10043973 | indir |
| XT200-025/1 | 25 | 35 | 9 | 8 | 10054134 | indir |
| XT200-025/2 | 25 | 33 | 5.6 | 5 | 10054135 | indir |
| XT200-028 | 28 | 36 | 6.3 | 5.7 | 10054136 | indir |
| XT200-028/1 | 28 | 38 | 9 | 8 | 10054137 | indir |
| XT200-030 | 30 | 38 | 6.3 | 5.7 | 10054138 | indir |
| XT200-030/1 | 30 | 40 | 9 | 8 | 10037843 | indir |
| XT200-030/2 | 30 | 45 | 11 | 10 | 10054139 | indir |
| XT200-030/3 | 30 | 40 | 6.7 | 6 | 10054140 | indir |
| XT200-032 | 32 | 40 | 6.3 | 5.7 | 10054141 | indir |
| XT200-032/1 | 32 | 47 | 11 | 10 | 10054142 | indir |
| XT200-035 | 35 | 43 | 6.3 | 5.7 | 10042207 | indir |
| XT200-035/1 | 35 | 45 | 9 | 8 | 10054143 | indir |
| XT200-035/2 | 35 | 50 | 11 | 10 | 10054144 | indir |
| XT200-035/3 | 35 | 45 | 6.7 | 6 | 10054145 | indir |
| XT200-036 | 36 | 44 | 6.3 | 5.7 | 10054146 | indir |
| XT200-040 | 40 | 50 | 9 | 8 | 10054147 | indir |
| XT200-040/1 | 40 | 48 | 6.3 | 5.7 | 10054148 | indir |
| XT200-040/2 | 40 | 48 | 9 | 8 | 10054149 | indir |
| XT200-040/3 | 40 | 50 | 8 | 7.3 | 10054150 | indir |
| XT200-040/4 | 40 | 50 | 10 | 9 | 10054151 | indir |
| XT200-040/5 | 40 | 50 | 11 | 10 | 10054152 | indir |
| XT200-040/6 | 40 | 55 | 11 | 10 | 10054153 | indir |
| XT200-040/7 | 40 | 50 | 6.7 | 6 | 10054154 | indir |
| XT200-045 | 45 | 53 | 9 | 8 | 10054155 | indir |
| XT200-045/1 | 45 | 55 | 9 | 8 | 10054156 | indir |
| XT200-045/2 | 45 | 60 | 11 | 10 | 10050878 | indir |
| XT200-045/3 | 45 | 55 | 6.7 | 6 | 10054157 | indir |
| XT200-045/4 | 45 | 53 | 6.3 | 5.7 | 10054158 | indir |
| XT200-050 | 50 | 60 | 8 | 7.3 | 10054159 | indir |
| XT200-050/1 | 50 | 65 | 11 | 10 | 10054160 | indir |
| XT200-050/2 | 50 | 58 | 9 | 8 | 10054161 | indir |
| XT200-050/3 | 50 | 60 | 9 | 8 | 10054162 | indir |
| XT200-050/4 | 50 | 60 | 11 | 10 | 10054163 | indir |
| XT200-050/5 | 50 | 65 | 12 | 11 | 10054164 | indir |
| XT200-050/6 | 50 | 60 | 6.7 | 6 | 10054165 | indir |
| XT200-055 | 55 | 65 | 8 | 7.3 | 10054166 | indir |
| XT200-055/1 | 55 | 65 | 9 | 8 | 10054167 | indir |
| XT200-055/2 | 55 | 70 | 11 | 10 | 10054168 | indir |
| XT200-055/3 | 55 | 65 | 6.7 | 6 | 10043826 | indir |
| XT200-055/4 | 55 | 75 | 13 | 12 | 10054169 | indir |
| XT200-056 | 56 | 66 | 9 | 8 | 10054170 | indir |
| XT200-056/1 | 56 | 66 | 11 | 10 | 10054171 | indir |
| XT200-056/2 | 56 | 71 | 11 | 10 | 10054172 | indir |
| XT200-060 | 60 | 68 | 9 | 8 | 10054173 | indir |
| XT200-060/1 | 60 | 70 | 8 | 7.3 | 10054174 | indir |
| XT200-060/2 | 60 | 70 | 9 | 8 | 10054175 | indir |
| XT200-060/3 | 60 | 75 | 11 | 10 | 10054176 | indir |
| XT200-060/4 | 60 | 70 | 6.7 | 6 | 10054177 | indir |
| XT200-060/5 | 60 | 80 | 13 | 12 | 10054178 | indir |
| XT200-063 | 63 | 78 | 11 | 10 | 10054179 | indir |
| XT200-065 | 65 | 75 | 9 | 8 | 10054180 | indir |
| XT200-065/1 | 65 | 80 | 13 | 12 | 10054181 | indir |
| XT200-065/2 | 65 | 75 | 6.7 | 6 | 10054182 | indir |
| XT200-065/3 | 65 | 85 | 13 | 12 | 10054183 | indir |
| XT200-070 | 70 | 80 | 9 | 8 | 10054184 | indir |
| XT200-070/1 | 70 | 82 | 9.6 | 8.6 | 10054185 | indir |
| XT200-070/2 | 70 | 90 | 13 | 12 | 10054186 | indir |
| XT200-070/3 | 70 | 80 | 6.7 | 6 | 10054187 | indir |
| XT200-075 | 75 | 90 | 11 | 10 | 10054188 | indir |
| XT200-075/1 | 75 | 85 | 6.7 | 6 | 10054189 | indir |
| XT200-080 | 80 | 90 | 11 | 10 | 10054190 | indir |
| XT200-080/1 | 80 | 95 | 12.5 | 11.5 | 10054191 | indir |
| XT200-080/2 | 80 | 100 | 13 | 12 | 10054192 | indir |
| XT200-080/3 | 80 | 90 | 8 | 7.3 | 10054193 | indir |
| XT200-080/4 | 80 | 90 | 6.7 | 6 | 10054194 | indir |
| XT200-085 | 85 | 100 | 10 | 9 | 10054195 | indir |
| XT200-085/1 | 85 | 95 | 9.6 | 8.6 | 10054196 | indir |
| XT200-085/2 | 85 | 105 | 13 | 12 | 10054197 | indir |
| XT200-085/3 | 85 | 100 | 11 | 10 | 10054198 | indir |
| XT200-085/4 | 85 | 97 | 9.7 | 8.7 | 10054199 | indir |
| XT200-090 | 90 | 105 | 11 | 10 | 10054200 | indir |
| XT200-090/1 | 90 | 110 | 13 | 12 | 10054201 | indir |
| XT200-090/2 | 90 | 105 | 10 | 9 | 10054202 | indir |
| XT200-095 | 95 | 110 | 10 | 9 | 10054203 | indir |
| XT200-095/1 | 95 | 110 | 11 | 10 | 10054204 | indir |
| XT200-100 | 100 | 115 | 10 | 9 | 10052093 | indir |
| XT200-100/1 | 100 | 115 | 11 | 10 | 10054205 | indir |
| XT200-100/2 | 100 | 115 | 13 | 12 | 10054206 | indir |
| XT200-100/3 | 100 | 120 | 13 | 12 | 10054207 | indir |
| XT200-105 | 105 | 120 | 10 | 9 | 10054208 | indir |
| XT200-105/1 | 105 | 120 | 11 | 10 | 10054209 | indir |
| XT200-110 | 110 | 125 | 10 | 9 | 10054210 | indir |
| XT200-110/1 | 110 | 130 | 16 | 14.5 | 10054211 | indir |
| XT200-110/2 | 110 | 125 | 11 | 10 | 10036928 | indir |
| XT200-115 | 115 | 130 | 10 | 9 | 10054212 | indir |
| XT200-115/1 | 115 | 130 | 11 | 10 | 10054213 | indir |
| XT200-120 | 120 | 140 | 16 | 14.5 | 10054214 | indir |
| XT200-125 | 125 | 140 | 10 | 9 | 10054215 | indir |
| XT200-130 | 130 | 145 | 11 | 10 | 10054216 | indir |
| XT200-130/1 | 130 | 150 | 13 | 12 | 10054217 | indir |
| XT200-140 | 140 | 155 | 10 | 9 | 10043411 | indir |
| XT200-140/1 | 140 | 160 | 13 | 12 | 10054218 | indir |
| XT200-145 | 145 | 160 | 11 | 10 | 10045848 | indir |
| XT200-150 | 150 | 170 | 16 | 14.5 | 10047436 | indir |
| XT200-150/1 | 150 | 170 | 13 | 12 | 10054219 | indir |
| XT200-150/2 | 150 | 165 | 11 | 10 | 10036927 | indir |
| XT200-160 | 160 | 180 | 16 | 14.5 | 10054220 | indir |
| XT200-160/1 | 160 | 180 | 13 | 12 | 10036926 | indir |
| XT200-170 | 170 | 190 | 16 | 14.5 | 10054221 | indir |
| XT200-180 | 180 | 200 | 13 | 12 | 10054222 | indir |
| XT200-180/1 | 180 | 200 | 16 | 14.5 | 10054223 | indir |
| XT200-190 | 190 | 210 | 16 | 14.5 | 10054224 | indir |
| XT200-200 | 200 | 220 | 16 | 14.5 | 10054225 | indir |
| XT200-220 | 220 | 240 | 16 | 14.5 | 10054226 | indir |
| XT200-220/1 | 220 | 240 | 13 | 12 | 10054227 | indir |
| XT200-240 | 240 | 260 | 16 | 14.5 | 10054228 | indir |
| XT200-250 | 250 | 270 | 16 | 14.5 | 10054229 | indir |
| XT200-025/3 | 25 | 35 | 8 | 7.3 | 10054233 | indir |
| XT200-032/2 | 32 | 42 | 8 | 7.3 | 10054234 | indir |
| XT200-036/1 | 36 | 46 | 9 | 8 | 10054244 | indir |
| XT200-050/7 | 50 | 58 | 6.3 | 5.7 | 10042214 | indir |
| XT200-060/7 | 60 | 70 | 11 | 10 | 10050710 | indir |
| XT200-120/1 | 120 | 135 | 10 | 9 | 10054245 | indir |
