Hidrolik Piston Sızdırmazlık Elemanları
K18
Kompakt Set
- Malzeme
- NBR TPE POM
- Kodu
- NB8001 TP7301 PM9901
- Basınç (max) bar
- 400
- Sıcaklık (max) °C
- -30/+100
- Kayma Hızı (max)- m/s
- 0.5
Avantajları
- Özel tasarımı sayesinde üstün sızdırmazlık ve düşük sürtünme özelliği
- Kompakt tasarımı sayesinde hafif ve orta hizmet kullanımlarında ilave yataklama elemanı ihtiyacı bulunmaması
- Ekonomik sızdırmazlık çözümü sunması
- Tek parçalı pistonda basit kanal tasarımı
- Uzun çalışma ömrü
- Kesimli yataklama ve destek ringleri sayesinde tek parça pistona kolay montaj yapılabilmesi
Uygulama Alanları
- Tarım sektörü
- İş makineleri sektörü
- Araç üstü sektörü
- Liftler
- Forkliftler
Teknik Çizim
Ölçü Tablosu
239 ölçü · Kod veya ölçü ile filtreleyin
239 sonuç
| Kod | D (H8) | d (h9) | L (+0.2/-0) | ds (h8) | d1 (±0.1) | L1 (+0.2/-0) | C | MALZEME | KASTAŞ KOD | |
|---|---|---|---|---|---|---|---|---|---|---|
| K18 020-011 | 20 | 11 | 13.5 | 17 | 19 | 2.1 | 4 | NB8001 | 10003121 | — |
| K18 022-013 | 22 | 13 | 13.5 | 19 | 21 | 2.1 | 4 | NB8001 | 10003123 | — |
| K18 025-015 | 25 | 15 | 16.4 | 21.45 | 23.5 | 6.35 | 4 | NB8001 | 10003124 | — |
| K18 025-015/1 | 25 | 15 | 12 | 21 | 23 | 4 | 4 | NB8001 | 10003125 | — |
| K18 025-015/2 | 25 | 15 | 12.5 | 22 | 24 | 4 | 4 | NB8001 | 10003126 | — |
| K18 025-016 | 25 | 16 | 13.5 | 22 | 24 | 2.1 | 4 | NB8001 | 10003127 | — |
| K18 025-017/1 | 25 | 17 | 13.5 | 21 | 24.4 | 3.2 | 4 | NB8001 | 10003130 | — |
| K18 025-017/2 | 25 | 17 | 10 | 22 | 24 | 4 | 4 | NB8001 | 10003131 | — |
| K18 028-019 | 28 | 19 | 13.5 | 25 | 27 | 2.1 | 4 | NB8001 | 10003133 | — |
| K18 030-017 | 30 | 17 | 15.4 | 26.5 | 28.5 | 6.35 | 4 | NB8001 | 10003134 | — |
| K18 030-021 | 30 | 21 | 13.5 | 27 | 29 | 2.1 | 4 | NB8001 | 10003136 | — |
| K18 030-022 | 30 | 22 | 13.5 | 26 | 29.4 | 3.2 | 4 | NB8001 | 10003137 | — |
| K18 032-019 | 32 | 19 | 15.4 | 28.5 | 30.7 | 6.35 | 4 | NB8001 | 10003138 | — |
| K18 032-022 | 32 | 22 | 16.4 | 28.5 | 30.5 | 6.35 | 4 | NB8001 | 10003139 | — |
| K18 032-022/1 | 32 | 22 | 15.5 | 28 | 31 | 2.6 | 4 | NB8001 | 10003140 | — |
| K18 032-022/2 | 32 | 22 | 12.5 | 29 | 31 | 4 | 4 | NB8001 | 10003143 | — |
| K18 032-024 | 32 | 24 | 15.5 | 28 | 31 | 3.1 | 4 | NB8001 | 10003145 | — |
| K18 032-024/1 | 32 | 24 | 10 | 29 | 31 | 4 | 4 | NB8001 | 10003147 | — |
| K18 035-025 | 35 | 25 | 16.4 | 31.4 | 33.5 | 6.35 | 4 | NB8001 | 10003149 | — |
| K18 035-027 | 35 | 27 | 15.5 | 31 | 34.4 | 3.2 | 4 | NB8001 | 10003151 | — |
| K18 038.1-025.4 | 1,5 | 1 | 0,625 | 1,36 | 1,46 | 0,25 | 0,157 | NB8001 | 10003153 | — |
| K18 040-024 | 40 | 24 | 18.4 | 35.4 | 38.5 | 6.35 | 5 | NB8001 | 10003155 | — |
| K18 040-026 | 40 | 26 | 15.5 | 36 | 39 | 2.6 | 4.5 | NB8001 | 10003158 | — |
| K18 040-030 | 40 | 30 | 16.4 | 35.4 | 38.5 | 6.35 | 4 | NB8001 | 10003161 | — |
| K18 040-030/1 | 40 | 30 | 12.5 | 37 | 39 | 4 | 4 | NB8001 | 10003164 | — |
| K18 040-030/2 | 40 | 30 | 12.4 | 36 | 39 | 4 | 4 | NB8001 | 10003167 | — |
| K18 040-032 | 40 | 32 | 15.5 | 36 | 39.4 | 3.2 | 4 | NB8001 | 10003169 | — |
| K18 040-032/1 | 40 | 32 | 10 | 37 | 39 | 4 | 4 | NB8001 | 10003171 | — |
| K18 042-028 | 42 | 28 | 15.5 | 38 | 41 | 2.6 | 4.5 | NB8001 | 10003173 | — |
| K18 044.45-028.57 | 1,75 | 1,125 | 0,75 | 1,569 | 1,698 | 0,25 | 0,197 | NB8001 | 10003174 | — |
| K18 045-029 | 45 | 29 | 18.4 | 40.4 | 43.5 | 6.35 | 5 | NB8001 | 10003175 | — |
| K18 045-031 | 45 | 31 | 15.5 | 41 | 44 | 2.6 | 4.5 | NB8001 | 10003177 | — |
| K18 045-035 | 45 | 35 | 16.4 | 40.4 | 43.5 | 6.35 | 4 | NB8001 | 10003179 | — |
| K18 045-037 | 45 | 37 | 15.5 | 41 | 44.4 | 3.2 | 4 | NB8001 | 10003182 | — |
| K18 050-034 | 50 | 34 | 20.5 | 46 | 49 | 3.1 | 5 | NB8001 | 10003185 | — |
| K18 050-034/1 | 50 | 34 | 18.4 | 45.41 | 48.66 | 6.35 | 5 | NB8001 | 10003188 | — |
| K18 050-035 | 50 | 35 | 20 | 46 | 48.5 | 5 | 5 | NB8001 | 10003192 | — |
| K18 050-038 | 50 | 38 | 20.5 | 46 | 49.4 | 4.2 | 4 | NB8001 | 10003194 | — |
| K18 050-040 | 50 | 40 | 12.5 | 47 | 49 | 4 | 4 | NB8001 | 10003197 | — |
| K18 050.8-034.92 | 2 | 1,375 | 0,75 | 1,82 | 1,948 | 0,25 | 0,197 | NB8001 | 10003183 | — |
| K18 050.8-041.27 | 2 | 1,625 | 0,437 | 1,822 | 1,937 | 0,15 | 0,157 | NB8001 | 10003184 | — |
| K18 055-039 | 55 | 39 | 20.5 | 51 | 54 | 3.1 | 5 | NB8001 | 10003200 | — |
| K18 055-039/1 | 55 | 39 | 18.4 | 50.37 | 53.65 | 6.35 | 5 | NB8001 | 10003202 | — |
| K18 055-045 | 55 | 45 | 12.5 | 52 | 54 | 4 | 4 | NB8001 | 10003205 | — |
| K18 056-040 | 56 | 40 | 20.5 | 52 | 55 | 3.1 | 5 | NB8001 | 10003206 | — |
| K18 057.15-041.27 | 2,25 | 1,625 | 0,75 | 2,069 | 2,197 | 0,25 | 0,197 | NB8001 | 10003207 | — |
| K18 060-044 | 60 | 44 | 20.5 | 56 | 59 | 3.1 | 5 | NB8001 | 10003209 | — |
| K18 060-044/1 | 60 | 44 | 18.4 | 55.39 | 58.65 | 6.35 | 5 | NB8001 | 10003213 | — |
| K18 060-048 | 60 | 48 | 20.5 | 56 | 58.98 | 4.2 | 4 | NB8001 | 10003217 | — |
| K18 060.32-044.45 | 2,375 | 1,75 | 0,75 | 2,194 | 2,322 | 0,25 | 0,197 | NB8001 | 10003208 | — |
| K18 063-047 | 63 | 47 | 20.5 | 59 | 62 | 3.1 | 5 | NB8001 | 10003222 | — |
| K18 063-047/1 | 63 | 47 | 18.4 | 58.39 | 61.63 | 6.35 | 55 | NB8001 | 10003225 | — |
| K18 063-047/2 | 63 | 47 | 19.4 | 58.47 | 61.5 | 6.35 | 5 | NB8001 | 10003228 | — |
| K18 063-048 | 63 | 48 | 20 | 59 | 61.5 | 5 | 5 | NB8001 | 10003231 | — |
| K18 063-051 | 63 | 51 | 20.5 | 59 | 62.4 | 4.2 | 4 | NB8001 | 10003234 | — |
| K18 063-053 | 63 | 53 | 12.5 | 60 | 62 | 4 | 4 | NB8001 | 10003237 | — |
| K18 063.5-047.62 | 2,5 | 1,875 | 0,75 | 2,319 | 2,446 | 0,25 | 0,197 | NB8001 | 10003219 | — |
| K18 063.5-053.97 | 2,5 | 2,125 | 0,437 | 2,328 | 2,446 | 0,15 | 0,157 | NB8001 | 10003220 | — |
| K18 063.5-053.97/1 | 2,5 | 2,125 | 0,437 | 2,32 | 2,437 | 0,15 | 0,157 | NB8001 | 10003221 | — |
| K18 065-049 | 65 | 49 | 20.5 | 61 | 64 | 3.1 | 5 | NB8001 | 10003239 | — |
| K18 065-050 | 65 | 50 | 18.4 | 60.41 | 63.64 | 6.35 | 5 | NB8001 | 10003242 | — |
| K18 066.67-050.80 | 2,625 | 2 | 0,75 | 2,445 | 2,57 | 0,25 | 0,197 | NB8001 | 10003245 | — |
| K18 067-051 | 67 | 51 | 18.4 | 62.4 | 65.6 | 6.35 | 5 | NB8001 | 10003246 | — |
| K18 069.85-050.8 | 2,75 | 2 | 0,937 | 2,522 | 2,711 | 0,25 | 0,197 | NB8001 | 10003247 | — |
| K18 070-050 | 70 | 50 | 22.4 | 64.18 | 68.34 | 6.35 | 6 | NB8001 | 10003248 | — |
| K18 070-054 | 70 | 54 | 20.5 | 66 | 69 | 3.1 | 5 | NB8001 | 10003252 | — |
| K18 070-055 | 70 | 55 | 20 | 66 | 68.5 | 5 | 5 | NB8001 | 10003257 | — |
| K18 070-058 | 70 | 58 | 20.5 | 66 | 69.4 | 4.2 | 4 | NB8001 | 10003258 | — |
| K18 075-055 | 75 | 55 | 22.4 | 69.2 | 73.3 | 6.35 | 6 | NB8001 | 10003261 | — |
| K18 075-059 | 75 | 59 | 20.5 | 71 | 74 | 3.1 | 5 | NB8001 | 10003265 | — |
| K18 076.2-057.15 | 3 | 2,25 | 0,953 | 2,771 | 2,933 | 0,25 | 0,197 | NB8001 | 10003267 | — |
| K18 076.2-060.32 | 3 | 2,375 | 0,75 | 2,794 | 2,92 | 0,25 | 0,197 | NB8001 | 10003268 | — |
| K18 076.2-066.67 | 3 | 2,625 | 0,437 | 2,82 | 2,937 | 0,15 | 0,157 | NB8001 | 10003269 | — |
| K18 080-060 | 80 | 60 | 22.4 | 74.15 | 78.3 | 6.35 | 6 | NB8001 | 10003271 | — |
| K18 080-060/1 | 80 | 60 | 35 | 72.62 | 77.54 | 9.52 | 6 | NB8001 | 10003275 | — |
| K18 080-060/2 | 80 | 60 | 25 | 75 | 78 | 6.35 | 6 | NB8001 | 10003277 | — |
| K18 080-062 | 80 | 62 | 22.5 | 76 | 79 | 3.6 | 5 | NB8001 | 10003280 | — |
| K18 080-065 | 80 | 65 | 20 | 76 | 78.5 | 5 | 5 | NB8001 | 10003283 | — |
| K18 080-066 | 80 | 66 | 22.4 | 76 | 79.4 | 5.2 | 4.5 | NB8001 | 10003285 | — |
| K18 082.55-063.5 | 3,25 | 2,5 | 0,953 | 3,021 | 3,185 | 0,25 | 0,197 | NB8001 | 10003287 | — |
| K18 085-065 | 85 | 65 | 22.4 | 79.15 | 83.3 | 6.35 | 6 | NB8001 | 10003288 | — |
| K18 085-065/1 | 85 | 65 | 21.4 | 79.15 | 83.3 | 6.35 | 6 | NB8001 | 10003291 | — |
| K18 085-075 | 85 | 75 | 20 | 81 | 83.35 | 4 | 4 | NB8001 | 10003293 | — |
| K18 088.9-069.85 | 3,5 | 2,75 | 0,953 | 3,271 | 3,434 | 0,25 | 0,197 | NB8001 | 10003294 | — |
| K18 088.9-069.85/1 | 3,5 | 2,75 | 1,187 | 3,235 | 3,437 | 0,25 | 0,197 | NB8001 | 10003295 | — |
| K18 088.9-076.2 | 3,5 | 3 | 0,562 | 3,265 | 3,437 | 0,21 | 0,157 | NB8001 | 10003296 | — |
| K18 090-070 | 90 | 70 | 22.4 | 84.15 | 88.3 | 6.35 | 6 | NB8001 | 10003297 | — |
| K18 090-072 | 90 | 72 | 22.5 | 86 | 89 | 3.2 | 5 | NB8001 | 10003300 | — |
| K18 090-072/1 | 90 | 72 | 22.5 | 86 | 89 | 3.6 | 5 | NB8001 | 10003302 | — |
| K18 090-075 | 90 | 75 | 20 | 86 | 88.5 | 5 | 5 | NB8001 | 10003304 | — |
| K18 090-076 | 90 | 76 | 22.4 | 86 | 89.4 | 5.2 | 4.5 | NB8001 | 10003305 | — |
| K18 095-075 | 95 | 75 | 22.4 | 89.15 | 93.31 | 6.5 | 6 | NB8001 | 10003308 | — |
| K18 095-081 | 95 | 81 | 22.4 | 91 | 94.4 | 5.2 | 4.5 | NB8001 | 10003309 | — |
| K18 100-075 | 100 | 75 | 22.4 | 93.13 | 98 | 6.35 | 6 | NB8001 | 10003310 | — |
| K18 100-080 | 100 | 80 | 25.4 | 95 | 98 | 6.35 | 6 | NB8001 | 10003314 | — |
| K18 100-080/1 | 100 | 80 | 35 | 92.61 | 97.51 | 9.52 | 6 | NB8001 | 10003316 | — |
| K18 100-080/2 | 100 | 80 | 25 | 95 | 98 | 6.35 | 6 | NB8001 | 10003318 | — |
| K18 100-082 | 100 | 82 | 22.5 | 96 | 99 | 3.6 | 5 | NB8001 | 10003319 | — |
| K18 100-085 | 100 | 85 | 20 | 96 | 98.5 | 5 | 5 | NB8001 | 10003322 | — |
| K18 100-086 | 100 | 86 | 22.4 | 96 | 99.4 | 5.2 | 4.5 | NB8001 | 10003324 | — |
| K18 101.6-082.55 | 4 | 3,25 | 0,937 | 3,77 | 3,94 | 0,25 | 0,197 | NB8001 | 10003327 | — |
| K18 105-080 | 105 | 80 | 22.4 | 98.1 | 103 | 6.5 | 6 | NB8001 | 10003329 | — |
| K18 105-080/1 | 105 | 80 | 22.4 | 98.1 | 103 | 6.35 | 6 | NB8001 | 10003331 | — |
| K18 107.95-088.9 | 4,25 | 3,5 | 0,937 | 4,019 | 4,182 | 0,25 | 0,197 | NB8001 | 10003332 | — |
| K18 110-085 | 110 | 85 | 22.4 | 103.1 | 108 | 6.35 | 6 | NB8001 | 10003333 | — |
| K18 110-085/1 | 110 | 85 | 25.4 | 103.1 | 108 | 6.35 | 6 | NB8001 | 10003337 | — |
| K18 110-090 | 110 | 90 | 35 | 102.6 | 107.51 | 9.52 | 6 | NB8001 | 10003338 | — |
| K18 110-090/1 | 110 | 90 | 25.3 | 104.1 | 108.3 | 6.4 | 6 | NB8001 | 10003339 | — |
| K18 110-092 | 110 | 92 | 22.5 | 106 | 109 | 3.6 | 5 | NB8001 | 10003340 | — |
| K18 110-095 | 110 | 95 | 20 | 105 | 108 | 5 | 5 | NB8001 | 10003342 | — |
| K18 110-096 | 110 | 96 | 22.4 | 106 | 109.4 | 5.2 | 4.5 | NB8001 | 10003343 | — |
| K18 114.3-088.9 | 4,5 | 3,5 | 1,25 | 4,229 | 4,422 | 0,25 | 0,236 | NB8001 | 10003345 | — |
| K18 115-090 | 115 | 90 | 22.4 | 108.1 | 113.02 | 6.35 | 6 | NB8001 | 10003346 | — |
| K18 115-097 | 115 | 97 | 22.4 | 111 | 114 | 4.2 | 5 | NB8001 | 10003348 | — |
| K18 115-097/1 | 115 | 97 | 22.5 | 111 | 114 | 3.6 | 5 | NB8001 | 10003350 | — |
| K18 115-101 | 115 | 101 | 22.4 | 111 | 114.4 | 5.2 | 4.5 | NB8001 | 10003351 | — |
| K18 120-095 | 120 | 95 | 22.4 | 113.1 | 118 | 6.35 | 6 | NB8001 | 10003353 | — |
| K18 120-100 | 120 | 100 | 35 | 112.8 | 117.5 | 9.5 | 6 | NB8001 | 10003357 | — |
| K18 120-106 | 120 | 106 | 22.4 | 116 | 119.4 | 5.2 | 4.5 | NB8001 | 10003358 | — |
| K18 125-100 | 125 | 100 | 25.4 | 118.1 | 123 | 6.35 | 6 | NB8001 | 10003360 | — |
| K18 125-100/1 | 125 | 100 | 45 | 116.82 | 122.33 | 12.7 | 6 | NB8001 | 10003363 | — |
| K18 125-100/2 | 125 | 100 | 32 | 119 | 123 | 10 | 6 | NB8001 | 10003365 | — |
| K18 125-103 | 125 | 103 | 26.5 | 121 | 124 | 5.1 | 6 | NB8001 | 10003366 | — |
| K18 125-105 | 125 | 105 | 25.4 | 120 | 123 | 6.35 | 6 | NB8001 | 10003368 | — |
| K18 125-105/1 | 125 | 105 | 25 | 120 | 123 | 6.35 | 6 | NB8001 | 10003370 | — |
| K18 125-108 | 125 | 108 | 26.5 | 121 | 124.4 | 7.2 | 5 | NB8001 | 10003372 | — |
| K18 127-101.6 | 5 | 4 | 1,266 | 4,728 | 4,92 | 0,375 | 0,236 | NB8001 | 10003374 | — |
| K18 127-101.6/1 | 5 | 4 | 1,266 | 4,728 | 4,92 | 0,375 | 0,236 | NB8001 | 10003375 | — |
| K18 130-105 | 130 | 105 | 25.4 | 123.1 | 128 | 6.35 | 6 | NB8001 | 10003376 | — |
| K18 130-105/1 | 130 | 105 | 25.4 | 123.1 | 128 | 9.52 | 6 | NB8001 | 10003379 | — |
| K18 130-105/2 | 130 | 105 | 25.4 | 122.6 | 127.5 | 9.52 | 6 | NB8001 | 10003381 | — |
| K18 133.35-107.95 | 5,25 | 4,25 | 1,25 | 4,977 | 5,169 | 0,25 | 0,236 | NB8001 | 10003383 | — |
| K18 135-110 | 135 | 110 | 25.4 | 127.6 | 132.5 | 9.52 | 6 | NB8001 | 10003384 | — |
| K18 135-110/1 | 135 | 110 | 25.4 | 128.1 | 133 | 6.35 | 6 | NB8001 | 10003385 | — |
| K18 139.7-114.3 | 5,5 | 4,5 | 1,25 | 5,213 | 5,402 | 0,374 | 0,236 | NB8001 | 10003386 | — |
| K18 139.7-114.3/1 | 5,5 | 4,5 | 1,25 | 5,213 | 5,402 | 0,256 | 0,236 | NB8001 | 10003387 | — |
| K18 140-115 | 140 | 115 | 25.4 | 132.6 | 137.5 | 6.35 | 6 | NB8001 | 10003388 | — |
| K18 140-115/1 | 140 | 115 | 25.4 | 132.6 | 137.5 | 9.52 | 6 | NB8001 | 10003390 | — |
| K18 140-115/2 | 140 | 115 | 25.4 | 133 | 138 | 6.35 | 6 | NB8001 | 10003393 | — |
| K18 140-115/4 | 140 | 115 | 45 | 131.7 | 137.36 | 12.7 | 6 | NB8001 | 10003396 | — |
| K18 140-115/5 | 140 | 115 | 32 | 134 | 138 | 10 | 6 | NB8001 | 10003397 | — |
| K18 140-118 | 140 | 118 | 26.5 | 136 | 139 | 5.1 | 6 | NB8001 | 10003399 | — |
| K18 140-120 | 140 | 120 | 25 | 135 | 138 | 6.35 | 6 | NB8001 | 10003402 | — |
| K18 140-123 | 140 | 123 | 26.5 | 136 | 139.4 | 7.2 | 5 | NB8001 | 10003404 | — |
| K18 145-120 | 145 | 120 | 25.4 | 137.6 | 142.5 | 9.52 | 6 | NB8001 | 10003406 | — |
| K18 150-125 | 150 | 125 | 25.4 | 142.6 | 147.5 | 9.5 | 6 | NB8001 | 10003408 | — |
| K18 150-125/1 | 150 | 125 | 25.4 | 143 | 148 | 6.35 | 6 | NB8001 | 10003410 | — |
| K18 150-128 | 150 | 128 | 26.5 | 146 | 149 | 5.1 | 6 | NB8001 | 10003413 | — |
| K18 150-130 | 150 | 130 | 25.4 | 144.1 | 148.3 | 6.35 | 6 | NB8001 | 10003415 | — |
| K18 150-133 | 150 | 133 | 26.5 | 146 | 149.4 | 7.2 | 5 | NB8001 | 10003416 | — |
| K18 152.4-127 | 6 | 5 | 1,25 | 5,709 | 5,902 | 0,375 | 0,236 | NB8001 | 10003417 | — |
| K18 152.4-127/1 | 6 | 5 | 1,5 | 5,736 | 5,937 | 0,375 | 0,236 | NB8001 | 10003419 | — |
| K18 155-130 | 155 | 130 | 25.4 | 148 | 153 | 6.35 | 6 | NB8001 | 10003420 | — |
| K18 155-130/1 | 155 | 130 | 25.4 | 147.6 | 152.5 | 9.52 | 6 | NB8001 | 10003422 | — |
| K18 160-130 | 160 | 130 | 25.4 | 153 | 157.5 | 6.35 | 6 | NB8001 | 10003424 | — |
| K18 160-130/1 | 160 | 130 | 25.4 | 152.6 | 157.5 | 9.52 | 6 | NB8001 | 10003427 | — |
| K18 160-130/2 | 160 | 130 | 25.4 | 153 | 157.5 | 9.52 | 6 | NB8001 | 10003428 | — |
| K18 160-135 | 160 | 135 | 25.4 | 152.6 | 157.5 | 9.52 | 6 | NB8001 | 10003429 | — |
| K18 160-135/1 | 160 | 135 | 45 | 151.72 | 157.1 | 12.7 | 6 | NB8001 | 10003431 | — |
| K18 160-135/2 | 160 | 135 | 32 | 154 | 158 | 10 | 6 | NB8001 | 10003433 | — |
| K18 160-138 | 160 | 138 | 26.5 | 156 | 159 | 5.1 | 6 | NB8001 | 10003434 | — |
| K18 160-140 | 160 | 140 | 25 | 155 | 158 | 6.35 | 6 | NB8001 | 10003437 | — |
| K18 160-143 | 160 | 143 | 26.5 | 156 | 159.4 | 7.2 | 5 | NB8001 | 10003439 | — |
| K18 165-140 | 165 | 140 | 25.4 | 157.6 | 162.5 | 9.52 | 6 | NB8001 | 10003443 | — |
| K18 165-143 | 165 | 143 | 26.5 | 161 | 163.5 | 5.25 | 6 | NB8001 | 10003444 | — |
| K18 165.1-139.62 | 6,5 | 5,497 | 1,28 | 6,226 | 6,417 | 0,254 | 0,236 | NB8001 | 10003441 | — |
| K18 165.1-139.7 | 6,5 | 5,5 | 1,256 | 6,213 | 6,402 | 0,254 | 0,236 | NB8001 | 10003442 | — |
| K18 170-140 | 170 | 140 | 25.4 | 163 | 168 | 6.4 | 6 | NB8001 | 10003446 | — |
| K18 170-145 | 170 | 145 | 25.4 | 161.72 | 167.1 | 12.7 | 6 | NB8001 | 10003447 | — |
| K18 170-148 | 170 | 148 | 26.5 | 166 | 169 | 5.1 | 6 | NB8001 | 10003448 | — |
| K18 175-150 | 175 | 150 | 25.4 | 166.72 | 172.1 | 12.7 | 6 | NB8001 | 10003449 | — |
| K18 177.8-152.4 | 7 | 6 | 1,25 | 6,713 | 6,91 | 0,375 | 0,236 | NB8001 | 10003450 | — |
| K18 177.8-152.4/1 | 7 | 6 | 1,25 | 6,713 | 6,91 | 0,254 | 0,236 | NB8001 | 10003451 | — |
| K18 180-150 | 180 | 150 | 35.4 | 172.95 | 177.87 | 6.35 | 6 | NB8001 | 10003452 | — |
| K18 180-150/1 | 180 | 150 | 36 | 172 | 177.87 | 12.5 | 6 | NB8001 | 10003454 | — |
| K18 180-155 | 180 | 155 | 25.4 | 171.72 | 177.1 | 12.7 | 6 | NB8001 | 10003455 | — |
| K18 180-158 | 180 | 158 | 26.5 | 176 | 179 | 5.1 | 6 | NB8001 | 10003457 | — |
| K18 180-163 | 180 | 163 | 26.5 | 176 | 179.4 | 7.2 | 5 | NB8001 | 10003459 | — |
| K18 185-160 | 185 | 160 | 25.4 | 176.72 | 182.1 | 12.7 | 6 | NB8001 | 10003461 | — |
| K18 190-165 | 190 | 165 | 25.4 | 181.72 | 187.05 | 12.7 | 6 | NB8001 | 10003462 | — |
| K18 195-170 | 195 | 170 | 25.4 | 187.1 | 192.05 | 12.7 | 6 | NB8001 | 10003464 | — |
| K18 200-170 | 200 | 170 | 35.4 | 193 | 198 | 6.35 | 6 | NB8001 | 10003466 | — |
| K18 200-170/1 | 200 | 170 | 36 | 192 | 197 | 12.5 | 6 | NB8001 | 10003469 | — |
| K18 200-175 | 200 | 175 | 31.5 | 196 | 199 | 6.6 | 6 | NB8001 | 10003471 | — |
| K18 200-175/1 | 200 | 175 | 25.4 | 191.62 | 197 | 12.7 | 6 | NB8001 | 10003474 | — |
| K18 200-180 | 200 | 180 | 31.5 | 196 | 199.4 | 9.2 | 6 | NB8001 | 10003476 | — |
| K18 203.2-171.45 | 8 | 6,75 | 1,5 | 7,681 | 7,92 | 0,315 | 0,236 | NB8001 | 10003479 | — |
| K18 203.2-177.8 | 8 | 7 | 1,25 | 7,723 | 7,92 | 0,375 | 0,236 | NB8001 | 10003480 | — |
| K18 203.2-177.8/1 | 8 | 7 | 1,25 | 7,723 | 7,917 | 0,25 | 0,236 | NB8001 | 10003481 | — |
| K18 210-185 | 210 | 185 | 25.4 | 201.62 | 207 | 12.7 | 6 | NB8001 | 10003482 | — |
| K18 220-190 | 220 | 190 | 35.4 | 212.7 | 217.9 | 6.35 | 6 | NB8001 | 10003483 | — |
| K18 220-190/1 | 220 | 190 | 35.4 | 213.5 | 217.9 | 6.35 | 6 | NB8001 | 10003485 | — |
| K18 220-195 | 220 | 195 | 25.4 | 211.62 | 217 | 12.7 | 6 | NB8001 | 10003486 | — |
| K18 220-200 | 220 | 200 | 31.5 | 216 | 219.4 | 9.2 | 6 | NB8001 | 10003487 | — |
| K18 225-195 | 225 | 195 | 35.5 | 218 | 223 | 6.35 | 6 | NB8001 | 10003489 | — |
| K18 225-200 | 225 | 200 | 31.5 | 221 | 224 | 6.6 | 6 | NB8001 | 10003490 | — |
| K18 225-200/1 | 225 | 200 | 25.4 | 216.6 | 223 | 12.7 | 6 | NB8001 | 10003491 | — |
| K18 230-205 | 230 | 205 | 25.4 | 221.62 | 227 | 12.7 | 6 | NB8001 | 10003492 | — |
| K18 240-215 | 240 | 215 | 25.4 | 231.62 | 237 | 12.7 | 6 | NB8001 | 10003493 | — |
| K18 250-220 | 250 | 220 | 35.4 | 242.9 | 247.85 | 6.35 | 6 | NB8001 | 10003494 | — |
| K18 250-225 | 250 | 225 | 25.4 | 241.62 | 247 | 12.7 | 6 | NB8001 | 10003496 | — |
| K18 250-230 | 250 | 230 | 31.5 | 246 | 249.4 | 9.2 | 6 | NB8001 | 10003500 | — |
| K18 260-235 | 260 | 235 | 35.4 | 252.9 | 257 | 12.7 | 6 | NB8001 | 10003502 | — |
| K18 280-250 | 280 | 250 | 36.4 | 273 | 278 | 10 | 6 | NB8001 | 10003504 | — |
| K18 280-250/1 | 280 | 250 | 35.4 | 272.9 | 277.85 | 9.52 | 6 | NB8001 | 10003506 | — |
| K18 038,1-025,4 | 1.5 | 1 | 1.36 | 0.157 | NB8001 | 10003153 | — | |||
| K18 044,45-028,57 | 1.75 | 1.125 | 1.569 | 0.197 | NB8001 | 10003174 | — | |||
| K18 050,8-034,92 | 2 | 1.375 | 1.82 | 0.197 | NB8001 | 10003183 | — | |||
| K18 050,8-041,27 | 2 | 1.625 | 1.822 | 0.157 | NB8001 | 10003184 | — | |||
| K18 057,15-041,27 | 2.25 | 1.625 | 2.069 | 0.197 | NB8001 | 10003207 | — | |||
| K18 060,32-044,45 | 2.375 | 1.75 | 2.194 | 0.197 | NB8001 | 10003208 | — | |||
| K18 063,5-047,62 | 2.5 | 1.875 | 2.319 | 0.197 | NB8001 | 10003219 | — | |||
| K18 063,5-053,97 | 2.5 | 2.125 | 2.328 | 0.157 | NB8001 | 10003220 | — | |||
| K18 063,5-053,97/1 | 2.5 | 2.125 | 2.32 | 0.157 | NB8001 | 10003221 | — | |||
| K18 069,85-050,8 | 2.75 | 2 | 2.522 | 0.197 | NB8001 | 10003247 | — | |||
| K18 076,2-057,15 | 3 | 2.25 | 2.771 | 0.197 | NB8001 | 10003267 | — | |||
| K18 076,2-060,32 | 3 | 2.375 | 2.794 | 0.197 | NB8001 | 10003268 | — | |||
| K18 076,2-066,67 | 3 | 2.625 | 2.82 | 0.157 | NB8001 | 10003269 | — | |||
| K18 082,55-063,5 | 3.25 | 2.5 | 3.021 | 0.197 | NB8001 | 10003287 | — | |||
| K18 088,9-069,85 | 3.5 | 2.75 | 3.271 | 0.197 | NB8001 | 10003294 | — | |||
| K18 088,9-069,85/1 | 3.5 | 2.75 | 3.235 | 0.197 | NB8001 | 10003295 | — | |||
| K18 088,9-076,2 | 3.5 | 3 | 3.265 | 0.157 | NB8001 | 10003296 | — | |||
| K18 101,6-082,55 | 4 | 3.25 | 3.77 | 0.197 | NB8001 | 10003327 | — | |||
| K18 107,95-088,9 | 4.25 | 3.5 | 4.019 | 0.197 | NB8001 | 10003332 | — | |||
| K18 114,3-088,9 | 4.5 | 3.5 | 4.229 | 0.236 | NB8001 | 10003345 | — | |||
| K18 127-101,6 | 5 | 4 | 4.728 | 0.236 | NB8001 | 10003374 | — | |||
| K18 127-101,6/1 | 5 | 4 | 4.728 | 0.236 | NB8001 | 10003375 | — | |||
| K18 133,35-107,95 | 5.25 | 4.25 | 4.977 | 0.236 | NB8001 | 10003383 | — | |||
| K18 139,7-114,3 | 5.5 | 4.5 | 5.213 | 0.236 | NB8001 | 10003386 | — | |||
| K18 139,7-114,3/1 | 5.5 | 4.5 | 5.213 | 0.236 | NB8001 | 10003387 | — | |||
| K18 152,4-127 | 6 | 5 | 5.709 | 0.236 | NB8001 | 10003417 | — | |||
| K18 152,4-127/1 | 6 | 5 | 5.736 | 0.236 | NB8001 | 10003419 | — | |||
| K18 165,1-139,62 | 6.5 | 5.497 | 6.226 | 0.236 | NB8001 | 10003441 | — | |||
| K18 165,1-139,7 | 6.5 | 5.5 | 6.213 | 0.236 | NB8001 | 10003442 | — | |||
| K18 177,8-152,4 | 7 | 6 | 6.713 | 0.236 | NB8001 | 10003450 | — | |||
| K18 177,8-152,4/1 | 7 | 6 | 6.713 | 0.236 | NB8001 | 10003451 | — | |||
| K18 203,2-171,45 | 8 | 6.75 | 7.681 | 0.236 | NB8001 | 10003479 | — | |||
| K18 203,2-177,8 | 8 | 7 | 7.723 | 0.236 | NB8001 | 10003480 | — | |||
| K18 203,2-177,8/1 | 8 | 7 | 7.723 | 0.236 | NB8001 | 10003481 | — |
