Hidrolik Piston-Boğaz Sızdırmazlık Elemanları
K36
Piston Boğaz Keçesi
- Malzeme
- NBR BEZLİ NBR
- Kodu
- NB8001 FB8001
- Basınç (max) bar
- 250
- Sıcaklık (max) °C
- -30/+105
- Kayma Hızı (max)- m/s
- 0.5
Avantajları
- Düşük basınçlarda yüksek ön yükleme ve elastomer malzeme ile iyi sızdırmazlık
- Bezli elastomer sayesinde yüksek akma ve kopma dayanımı
- Zor şartlarda çalışabilmesi
- Basit kanal tasarımı
Uygulama Alanları
- Standart hidrolik silindirler
- Mobil hidrolik silindirleri
- Endüstriyel silindirler
Teknik Çizim
Ölçü Tablosu
136 ölçü · Kod veya ölçü ile filtreleyin
Akma boşluğu (S) tablosu için tıklayınız
136 sonuç
| Kod | d(h9) dp(f8) | Db(H10) D(H9) | L (+0.2/-0) | C | MALZEME | KASTAŞ KOD | |
|---|---|---|---|---|---|---|---|
| K36-004 | 0,187 | 0,5 | 0,25 | 0,197 | NB8001 | 10017846 | — |
| K36-010 | 10 | 17 | 6.3 | 5 | NB8001 | 10017847 | — |
| K36-019 | 0,768 | 1,083 | 0,327 | 0,197 | NB8001 | 10017865 | — |
| K36-010/1 | 10 | 19 | 6.3 | 5 | NB8001 | 10017848 | — |
| K36-019/1 | 0,768 | 1,083 | 0,315 | 0,197 | NB8001 | 10017866 | — |
| K36-012 | 12 | 20 | 6.3 | 5 | NB8001 | 10017849 | — |
| K36-025/7 | 1 | 1,25 | 0,187 | 0,197 | NB8001 | 10017900 | — |
| K36-014 | 14 | 22 | 6.3 | 5 | NB8001 | 10017851 | — |
| K36-028/4 | 1,125 | 1,625 | 0,394 | 0,197 | NB8001 | 10017907 | — |
| K36-014/1 | 14 | 22 | 7 | 5 | NB8001 | 10017853 | — |
| K36-031 | 1,25 | 1,875 | 0,456 | 0,197 | NB8001 | 10017924 | — |
| K36-014/2 | 14 | 22 | 8.5 | 5 | NB8001 | 10017854 | — |
| K36-038/1 | 1,5 | 2 | 0,488 | 0,197 | NB8001 | 10017944 | — |
| K36-015 | 15 | 23 | 6.3 | 5 | NB8001 | 10017856 | — |
| K36-044 | 1,75 | 2,375 | 0,437 | 0,197 | NB8001 | 10017963 | — |
| K36-016 | 16 | 24 | 6.3 | 5 | NB8001 | 10017857 | — |
| K36-063 | 2,5 | 3,25 | 0,562 | 0,197 | NB8001 | 10018015 | — |
| K36-016/1 | 16 | 24 | 6.5 | 5 | NB8001 | 10017859 | — |
| K36-088 | 3,5 | 4 | 0,394 | 0,197 | NB8001 | 10018047 | — |
| K36-016/2 | 16 | 24 | 7 | 5 | NB8001 | 10017861 | — |
| K36-018 | 18 | 26 | 6.3 | 5 | NB8001 | 10017862 | — |
| K36-018/1 | 18 | 24 | 5.2 | 5 | NB8001 | 10017864 | — |
| K36-020 | 20 | 28 | 6.3 | 5 | NB8001 | 10017867 | — |
| K36-020/1 | 20 | 26 | 5.5 | 5 | NB8001 | 10017869 | — |
| K36-020/2 | 20 | 27 | 6.5 | 5 | NB8001 | 10017870 | — |
| K36-020/3 | 20 | 28 | 7 | 5 | NB8001 | 10017872 | — |
| K36-020/4 | 20 | 30 | 8.5 | 5 | NB8001 | 10017873 | — |
| K36-020/5 | 20 | 28 | 6 | 5 | NB8001 | 10017875 | — |
| K36-020/6 | 20 | 30 | 8 | 5 | NB8001 | 10017876 | — |
| K36-022 | 22 | 30 | 6.3 | 5 | NB8001 | 10017878 | — |
| K36-022/1 | 22 | 30 | 6.5 | 5 | NB8001 | 10017880 | — |
| K36-022/2 | 22 | 30 | 7 | 5 | NB8001 | 10017882 | — |
| K36-022/3 | 22 | 32 | 7.3 | 5 | NB8001 | 10017883 | — |
| K36-022/4 | 22 | 32 | 7 | 5 | NB8001 | 10017885 | — |
| K36-022/5 | 22 | 28 | 5.3 | 5 | NB8001 | 10017886 | — |
| K36-025 | 25 | 32 | 6.3 | 5 | NB8001 | 10017888 | — |
| K36-025/1 | 25 | 33 | 6.3 | 5 | NB8001 | 10017889 | — |
| K36-025/2 | 25 | 33 | 6 | 5 | NB8001 | 10017891 | — |
| K36-025/3 | 25 | 35 | 8.3 | 5 | NB8001 | 10017894 | — |
| K36-025/4 | 25 | 33 | 6.4 | 5 | NB8001 | 10017895 | — |
| K36-025/5 | 25 | 35 | 9 | 5 | NB8001 | 10017897 | — |
| K36-025/6 | 25 | 35 | 6 | 5 | NB8001 | 10017899 | — |
| K36-028 | 28 | 36 | 6.3 | 5 | NB8001 | 10017901 | — |
| K36-028/1 | 28 | 43 | 11 | 5 | NB8001 | 10017903 | — |
| K36-028/2 | 28 | 35 | 4.5 | 5 | NB8001 | 10017904 | — |
| K36-028/3 | 28 | 36 | 6.4 | 5 | NB8001 | 10017905 | — |
| K36-028/5 | 28 | 36 | 6 | 5 | NB8001 | 10017908 | — |
| K36-030 | 30 | 38 | 6.3 | 5 | NB8001 | 10017912 | — |
| K36-030/1 | 30 | 38 | 6 | 5 | NB8001 | 10017913 | — |
| K36-030/2 | 30 | 40 | 6.3 | 5 | NB8001 | 10017915 | — |
| K36-030/3 | 30 | 40 | 7.5 | 5 | NB8001 | 10017916 | — |
| K36-030/4 | 30 | 40 | 7 | 5 | NB8001 | 10017918 | — |
| K36-030/5 | 30 | 50 | 14.5 | 5 | NB8001 | 10017919 | — |
| K36-030/6 | 30 | 38 | 6.4 | 5 | NB8001 | 10017920 | — |
| K36-030/7 | 30 | 37.5 | 6.5 | 5 | NB8001 | 10017922 | — |
| K36-030/8 | 30 | 40 | 6 | 5 | NB8001 | 10017923 | — |
| K36-032 | 32 | 40 | 6.3 | 5 | NB8001 | 10017925 | — |
| K36-032/1 | 32 | 44 | 12.5 | 5 | NB8001 | 10017927 | — |
| K36-035 | 35 | 43 | 6.3 | 5 | NB8001 | 10017928 | — |
| K36-035/1 | 35 | 45 | 8 | 5 | NB8001 | 10017930 | — |
| K36-035/2 | 35 | 43 | 6 | 5 | NB8001 | 10017932 | — |
| K36-035/3 | 35 | 50 | 11.5 | 5 | NB8001 | 10017933 | — |
| K36-035/4 | 35 | 43 | 6.5 | 5 | NB8001 | 10017934 | — |
| K36-035/5 | 35 | 43 | 7.3 | 5 | NB8001 | 10017936 | — |
| K36-035/6 | 35 | 45 | 7.5 | 5 | NB8001 | 10017937 | — |
| K36-035/7 | 35 | 43 | 7 | 5 | NB8001 | 10017939 | — |
| K36-036 | 36 | 44 | 6.3 | 5 | NB8001 | 10017940 | — |
| K36-036/1 | 36 | 51 | 11 | 5 | NB8001 | 10017942 | — |
| K36-038 | 38 | 50 | 9.5 | 5 | NB8001 | 10017943 | — |
| K36-040 | 40 | 48 | 6.3 | 5 | NB8001 | 10017946 | — |
| K36-040/1 | 40 | 50 | 8 | 5 | NB8001 | 10017948 | — |
| K36-040/2 | 40 | 48 | 8 | 5 | NB8001 | 10017950 | — |
| K36-040/3 | 40 | 50 | 7 | 5 | NB8001 | 10017952 | — |
| K36-040/4 | 40 | 48 | 6.5 | 5 | NB8001 | 10017954 | — |
| K36-040/5 | 40 | 60 | 14.5 | 5 | NB8001 | 10017956 | — |
| K36-040/6 | 40 | 50 | 11 | 5 | NB8001 | 10017958 | — |
| K36-040/7 | 40 | 48 | 7.3 | 5 | NB8001 | 10017960 | — |
| K36-040/8 | 40 | 48 | 7 | 5 | NB8001 | 10017961 | — |
| K36-042 | 42 | 50 | 6.3 | 5 | NB8001 | 10017962 | — |
| K36-045 | 45 | 53 | 8.5 | 5 | NB8001 | 10017964 | — |
| K36-045/1 | 45 | 55 | 8 | 5 | NB8001 | 10017966 | — |
| K36-045/2 | 45 | 55 | 10.5 | 5 | NB8001 | 10017968 | — |
| K36-045/3 | 45 | 60 | 11 | 5 | NB8001 | 10017969 | — |
| K36-045/4 | 45 | 57 | 9.5 | 5 | NB8001 | 10017971 | — |
| K36-045/5 | 45 | 65 | 14.5 | 5 | NB8001 | 10017972 | — |
| K36-045/6 | 45 | 53 | 6.3 | 5 | NB8001 | 10017974 | — |
| K36-045/7 | 45 | 53 | 6 | 5 | NB8001 | 10017976 | — |
| K36-045/8 | 45 | 60 | 12 | 5 | NB8001 | 10017977 | — |
| K36-046 | 46 | 56 | 8 | 5 | NB8001 | 10017978 | — |
| K36-048 | 48 | 60 | 10 | 5 | NB8001 | 10017979 | — |
| K36-048/1 | 48 | 63 | 11 | 5 | NB8001 | 10017980 | — |
| K36-050 | 50 | 62 | 9.5 | 5 | NB8001 | 10017982 | — |
| K36-050/1 | 50 | 60 | 7.5 | 5 | NB8001 | 10017983 | — |
| K36-050/2 | 50 | 60 | 8 | 5 | NB8001 | 10017985 | — |
| K36-050/3 | 50 | 60 | 10 | 5 | NB8001 | 10017987 | — |
| K36-050/4 | 50 | 70 | 14.5 | 5 | NB8001 | 10017989 | — |
| K36-055 | 55 | 65 | 8 | 5 | NB8001 | 10017993 | — |
| K36-055/1 | 55 | 67 | 10.5 | 5 | NB8001 | 10017996 | — |
| K36-055/2 | 55 | 70 | 10.5 | 5 | NB8001 | 10017997 | — |
| K36-055/3 | 55 | 63 | 8.3 | 5 | NB8001 | 10017998 | — |
| K36-056 | 56 | 66 | 8 | 5 | NB8001 | 10017999 | — |
| K36-056/1 | 56 | 76 | 14 | 5 | NB8001 | 10018001 | — |
| K36-060 | 60 | 70 | 8 | 5 | NB8001 | 10018004 | — |
| K36-060/1 | 60 | 70 | 7.5 | 5 | NB8001 | 10018006 | — |
| K36-060/2 | 60 | 72 | 9.5 | 5 | NB8001 | 10018008 | — |
| K36-060/3 | 60 | 80 | 12.5 | 5 | NB8001 | 10018009 | — |
| K36-060/4 | 60 | 72 | 10 | 5 | NB8001 | 10018011 | — |
| K36-060/5 | 60 | 75 | 13 | 5 | NB8001 | 10018012 | — |
| K36-060/6 | 60 | 80 | 14.5 | 5 | NB8001 | 10018014 | — |
| K36-065 | 65 | 73 | 9.6 | 5 | NB8001 | 10018016 | — |
| K36-065/1 | 65 | 77 | 9.6 | 5 | NB8001 | 10018017 | — |
| K36-065/2 | 65 | 85 | 14.5 | 5 | NB8001 | 10018018 | — |
| K36-070 | 70 | 80 | 7.5 | 5 | NB8001 | 10018020 | — |
| K36-070/1 | 70 | 82 | 9.6 | 5 | NB8001 | 10018022 | — |
| K36-070/2 | 70 | 82 | 9 | 5 | NB8001 | 10018024 | — |
| K36-070/3 | 70 | 90 | 14 | 5 | NB8001 | 10018026 | — |
| K36-070/4 | 70 | 85 | 8 | 5 | NB8001 | 10018027 | — |
| K36-070/5 | 70 | 80 | 8 | 5 | NB8001 | 10018028 | — |
| K36-070/6 | 70 | 85 | 12 | 5 | NB8001 | 10018029 | — |
| K36-075 | 75 | 87 | 9.3 | 5 | NB8001 | 10018031 | — |
| K36-075/1 | 75 | 85 | 8 | 5 | NB8001 | 10018032 | — |
| K36-080 | 80 | 92 | 9.6 | 5 | NB8001 | 10018036 | — |
| K36-080/1 | 80 | 96 | 10 | 5 | NB8001 | 10018038 | — |
| K36-080/2 | 80 | 92 | 9 | 5 | NB8001 | 10018039 | — |
| K36-080/3 | 80 | 90 | 8 | 5 | NB8001 | 10018040 | — |
| K36-080/4 | 80 | 100 | 14 | 5 | NB8001 | 10018042 | — |
| K36-085 | 85 | 97 | 9.6 | 5 | NB8001 | 10018044 | — |
| K36-085/1 | 85 | 110 | 13.5 | 5 | NB8001 | 10018045 | — |
| K36-090 | 90 | 102 | 9.6 | 5 | NB8001 | 10018052 | — |
| K36-090/1 | 90 | 110 | 12.5 | 5 | NB8001 | 10018054 | — |
| K36-095 | 95 | 110 | 12.5 | 5 | NB8001 | 10018056 | — |
| K36-100 | 100 | 115 | 12 | 7 | NB8001 | 10018058 | — |
| K36-100/1 | 100 | 120 | 14 | 7 | NB8001 | 10018060 | — |
| K36-110 | 110 | 125 | 12 | 7 | NB8001 | 10018062 | — |
| K36-110/1 | 110 | 130 | 12 | 7 | NB8001 | 10018064 | — |
| K36-140 | 140 | 155 | 14 | 7 | NB8001 | 10018073 | — |
