Yataklama Elemanları
K75
Piston-Boğaz Yataklamaları
- Malzeme
- PTFE KATKILI SENTETİK FİBER FENOLİK RESİN
- Kodu
- PH6501
- Sıcaklık (max) °C
- -40/+130
- Kayma Hızı (max)- m/s
- 1.0
Avantajları
- Düşük sürtünme katsayısı
- Keçe arkasında kuru ortamda çalışabilmesi
- Çalışma sıcaklık aralığında ölçü stabilizasyonunun yüksek olması
- Kolay montaj yapılabilmesi
- Geniş ölçü yelpazesi
- Ağır ve orta hizmet uygulamalarında kullanılabilmesi
Uygulama Alanları
- Araç üstü sektörü
- Maden sektörü
- Ekskavatörler
- Presler
- Ağır hizmet silindirleri
Teknik Çizim
Ölçü Tablosu
148 ölçü · Kod veya ölçü ile filtreleyin
148 sonuç
| Kod | d(f8) dp(h8) | Db(H8) D(H9) | L (+0.2/-0) | H | d1 (h9) | D1 (H9) | MALZEME | KASTAŞ KOD | |
|---|---|---|---|---|---|---|---|---|---|
| K75-025 | 25 | 30 | 9.7 | 9.5 | 28.2 | 26.8 | PH6501 | 20000906 | — |
| K75-063.5/1 | 2.5 | 2.619 | 0.244 | 0.236 | 2.58 | 2.539 | PH6501 | 20000932 | — |
| K75-030 | 30 | 35 | 9.7 | 9.5 | 33.2 | 31.8 | PH6501 | 20000908 | — |
| K75-035 | 35 | 40 | 15 | 14.8 | 38.2 | 36.8 | PH6501 | 20000909 | — |
| K75-035/1 | 35 | 40 | 9.7 | 9.5 | 38.2 | 36.8 | PH6501 | 20000910 | — |
| K75-036 | 36 | 40 | 10 | 9.8 | 39 | 37 | PH6501 | 20000911 | — |
| K75-040/1 | 40 | 45 | 9.7 | 9.5 | 43.2 | 41.8 | PH6501 | 20000913 | — |
| K75-040/2 | 40 | 45 | 15 | 14.8 | 43.2 | 41.8 | PH6501 | 20000914 | — |
| K75-040/3 | 40 | 44 | 15 | 14.8 | 43 | 41 | PH6501 | 20000915 | — |
| K75-045 | 45 | 50 | 9.7 | 9.5 | 48.2 | 46.8 | PH6501 | 20000916 | — |
| K75-045/1 | 45 | 50 | 15 | 14.8 | 48.2 | 46.8 | PH6501 | 20000917 | — |
| K75-050 | 50 | 55 | 9.7 | 9.5 | 53.2 | 51.8 | PH6501 | 20000918 | — |
| K75-050/1 | 50 | 55 | 15 | 14.8 | 53.2 | 51.8 | PH6501 | 20000919 | — |
| K75-050/2 | 50 | 54 | 10 | 9.8 | 53 | 51 | PH6501 | 20000920 | — |
| K75-055 | 55 | 60 | 15 | 14.8 | 58.2 | 56.8 | PH6501 | 20000921 | — |
| K75-055/1 | 55 | 60 | 9.7 | 9.5 | 58.2 | 56.8 | PH6501 | 20000922 | — |
| K75-056 | 56 | 62 | 8.1 | 7.9 | 59.6 | 58.4 | PH6501 | 20000923 | — |
| K75-056/1 | 56 | 62 | 12.5 | 12.3 | 59.6 | 58.4 | PH6501 | 20000924 | — |
| K75-056/2 | 56 | 62 | 20 | 19.8 | 59.6 | 58.4 | PH6501 | 20000925 | — |
| K75-056/3 | 56 | 61 | 15 | 14.8 | 59.2 | 57.8 | PH6501 | 20000926 | — |
| K75-058 | 58 | 63 | 9.7 | 9.5 | 61.2 | 59.8 | PH6501 | 20000927 | — |
| K75-060 | 60 | 65 | 15 | 14.8 | 63.2 | 61.8 | PH6501 | 20000928 | — |
| K75-060/1 | 60 | 65 | 9.7 | 9.5 | 63.2 | 61.8 | PH6501 | 20000929 | — |
| K75-060/2 | 60 | 65 | 20 | 19.8 | 63.2 | 61.8 | PH6501 | 20000930 | — |
| K75-063 | 63 | 68 | 15 | 14.8 | 66.2 | 64.8 | PH6501 | 20000931 | — |
| K75-063/1 | 63 | 68 | 9.7 | 9.5 | 66.2 | 64.8 | PH6501 | 20000933 | — |
| K75-065 | 65 | 70 | 15 | 14.8 | 68.2 | 66.8 | PH6501 | 20000934 | — |
| K75-065/1 | 65 | 70 | 9.7 | 9.5 | 68.2 | 66.8 | PH6501 | 20000935 | — |
| K75-070 | 70 | 75 | 9.7 | 9.5 | 73.2 | 71.8 | PH6501 | 20000936 | — |
| K75-070/1 | 70 | 75 | 15 | 14.8 | 73.2 | 71.8 | PH6501 | 20000937 | — |
| K75-070/2 | 70 | 75 | 20 | 19.8 | 73.2 | 71.8 | PH6501 | 20000938 | — |
| K75-074 | 74 | 80 | 6.5 | 6.3 | 77.6 | 76.4 | PH6501 | 20000939 | — |
| K75-075 | 75 | 80 | 9.7 | 9.5 | 78.2 | 76.8 | PH6501 | 20000940 | — |
| K75-075/1 | 75 | 80 | 15 | 14.8 | 78.2 | 76.8 | PH6501 | 20000941 | — |
| K75-080 | 80 | 85 | 9.7 | 9.5 | 83.2 | 81.8 | PH6501 | 20000942 | — |
| K75-080/1 | 80 | 85 | 15 | 14.8 | 83.2 | 81.8 | PH6501 | 20000943 | — |
| K75-080/2 | 80 | 85 | 20 | 19.8 | 83.2 | 81.8 | PH6501 | 20000944 | — |
| K75-080/3 | 80 | 86 | 30 | 29.8 | 83.6 | 82.4 | PH6501 | 20000945 | — |
| K75-084 | 84 | 90 | 6.5 | 6.3 | 87.6 | 86.4 | PH6501 | 20000946 | — |
| K75-085 | 85 | 90 | 9.7 | 9.5 | 88.2 | 86.8 | PH6501 | 20000947 | — |
| K75-085/1 | 85 | 90 | 15 | 14.8 | 88.2 | 86.8 | PH6501 | 20000948 | — |
| K75-085/2 | 85 | 90 | 25 | 24.8 | 88.2 | 86.8 | PH6501 | 20000949 | — |
| K75-085/3 | 85 | 90 | 20 | 19.8 | 88.2 | 86.8 | PH6501 | 20000950 | — |
| K75-090 | 90 | 95 | 15 | 14.8 | 93.2 | 91.8 | PH6501 | 20000951 | — |
| K75-090/1 | 90 | 95 | 9.7 | 9.5 | 93.2 | 91.8 | PH6501 | 20000952 | — |
| K75-090/2 | 90 | 95 | 5.6 | 5.4 | 93.2 | 91.8 | PH6501 | 20000953 | — |
| K75-094 | 94 | 100 | 6.5 | 6.3 | 97.6 | 96.4 | PH6501 | 20000954 | — |
| K75-095 | 95 | 100 | 9.7 | 9.5 | 98.2 | 96.8 | PH6501 | 20000955 | — |
| K75-095/1 | 95 | 100 | 15 | 14.8 | 98.2 | 96.8 | PH6501 | 20000956 | — |
| K75-095/2 | 95 | 100 | 20 | 19.8 | 98.2 | 96.8 | PH6501 | 20000957 | — |
| K75-100 | 100 | 105 | 15 | 14.8 | 103.2 | 101.8 | PH6501 | 20000958 | — |
| K75-100/1 | 100 | 105 | 9.7 | 9.5 | 103.2 | 101.8 | PH6501 | 20000959 | — |
| K75-100/2 | 100 | 105 | 20 | 19.8 | 103.2 | 101.8 | PH6501 | 20000960 | — |
| K75-100/3 | 100 | 105 | 25 | 24.8 | 103.2 | 101.8 | PH6501 | 20000961 | — |
| K75-105 | 105 | 110 | 9.7 | 9.5 | 108.2 | 106.8 | PH6501 | 20000965 | — |
| K75-105/1 | 105 | 110 | 15 | 14.8 | 108.2 | 106.8 | PH6501 | 20000966 | — |
| K75-105/2 | 105 | 110 | 5.6 | 5.4 | 108.2 | 106.8 | PH6501 | 20000967 | — |
| K75-105/3 | 105 | 110 | 20 | 19.8 | 108.2 | 106.8 | PH6501 | 20000968 | — |
| K75-109 | 109 | 115 | 6.5 | 6.3 | 112.6 | 111.4 | PH6501 | 20000970 | — |
| K75-110 | 110 | 115 | 9.7 | 9.5 | 113.2 | 111.8 | PH6501 | 20000971 | — |
| K75-110/1 | 110 | 115 | 15 | 14.8 | 113.2 | 111.8 | PH6501 | 20000972 | — |
| K75-110/2 | 110 | 115 | 5.6 | 5.4 | 113.2 | 111.8 | PH6501 | 20000973 | — |
| K75-113 | 113 | 118 | 15 | 14.8 | 116.2 | 114.8 | PH6501 | 20000974 | — |
| K75-115 | 115 | 120 | 9.7 | 9.5 | 118.2 | 116.8 | PH6501 | 20000975 | — |
| K75-115/1 | 115 | 120 | 15 | 14.8 | 118.2 | 116.8 | PH6501 | 20000976 | — |
| K75-115/2 | 115 | 120 | 25 | 24.8 | 118.2 | 116.8 | PH6501 | 20000977 | — |
| K75-119 | 119 | 125 | 25 | 24.8 | 122.6 | 121.4 | PH6501 | 20000978 | — |
| K75-120 | 120 | 125 | 9.7 | 9.5 | 123.2 | 121.8 | PH6501 | 20000979 | — |
| K75-120/1 | 120 | 125 | 15 | 14.8 | 123.2 | 121.8 | PH6501 | 20000980 | — |
| K75-120/2 | 120 | 125 | 20 | 19.8 | 123.2 | 121.8 | PH6501 | 20000981 | — |
| K75-120/3 | 120 | 125 | 25 | 24.8 | 123.2 | 121.8 | PH6501 | 20000982 | — |
| K75-121 | 121 | 126 | 9.7 | 9.5 | 124.2 | 122.8 | PH6501 | 20000984 | — |
| K75-125 | 125 | 130 | 9.7 | 9.5 | 128.2 | 126.8 | PH6501 | 20000985 | — |
| K75-125/1 | 125 | 130 | 15 | 14.8 | 128.2 | 126.8 | PH6501 | 20000986 | — |
| K75-130 | 130 | 135 | 9.7 | 9.5 | 133.2 | 131.8 | PH6501 | 20000988 | — |
| K75-130/1 | 130 | 135 | 15 | 14.8 | 133.2 | 131.8 | PH6501 | 20000989 | — |
| K75-130/2 | 130 | 135 | 25 | 24.8 | 133.2 | 131.8 | PH6501 | 20000990 | — |
| K75-135 | 135 | 140 | 9.7 | 9.5 | 138.2 | 136.8 | PH6501 | 20000991 | — |
| K75-135/1 | 135 | 140 | 15 | 14.8 | 138.2 | 136.8 | PH6501 | 20000992 | — |
| K75-135/2 | 135 | 140 | 20 | 19.8 | 138.2 | 136.8 | PH6501 | 20000993 | — |
| K75-140 | 140 | 145 | 9.7 | 9.5 | 143.2 | 141.8 | PH6501 | 20000995 | — |
| K75-140/1 | 140 | 145 | 15 | 14.8 | 143.2 | 141.8 | PH6501 | 20000996 | — |
| K75-140/2 | 140 | 148 | 25 | 24.8 | 145 | 143 | PH6501 | 20000997 | — |
| K75-142 | 142 | 147 | 15 | 14.8 | 145.2 | 143.8 | PH6501 | 20000998 | — |
| K75-142/1 | 142 | 147 | 9.7 | 9.5 | 145.2 | 143.8 | PH6501 | 20000999 | — |
| K75-143 | 143 | 150 | 20 | 19.8 | 147 | 146 | PH6501 | 20001000 | — |
| K75-145 | 145 | 150 | 9.7 | 9.5 | 148.2 | 146.8 | PH6501 | 20001001 | — |
| K75-145/1 | 145 | 150 | 15 | 14.8 | 148.2 | 146.8 | PH6501 | 20001002 | — |
| K75-145/2 | 145 | 150 | 25 | 24.8 | 148.2 | 146.8 | PH6501 | 20001003 | — |
| K75-148 | 148 | 160 | 15 | 14.8 | 157 | 151 | PH6501 | 20001004 | — |
| K75-150 | 150 | 155 | 15 | 14.8 | 153.2 | 151.8 | PH6501 | 20001005 | — |
| K75-150/1 | 150 | 155 | 9.7 | 9.5 | 153.2 | 151.8 | PH6501 | 20001006 | — |
| K75-155 | 155 | 160 | 9.7 | 9.5 | 158.2 | 156.8 | PH6501 | 20001008 | — |
| K75-155/1 | 155 | 160 | 15 | 14.8 | 158.2 | 156.8 | PH6501 | 20001009 | — |
| K75-155/2 | 155 | 163 | 25 | 24.8 | 160 | 158 | PH6501 | 20001010 | — |
| K75-155/3 | 155 | 160 | 20 | 19.8 | 158.2 | 156.8 | PH6501 | 20001011 | — |
| K75-160 | 160 | 165 | 20 | 19.8 | 163.2 | 161.8 | PH6501 | 20001012 | — |
| K75-160/1 | 160 | 165 | 15 | 14.8 | 163.2 | 161.8 | PH6501 | 20001013 | — |
| K75-165 | 165 | 170 | 9.7 | 9.5 | 168.2 | 166.8 | PH6501 | 20001014 | — |
| K75-175 | 175 | 180 | 9.7 | 9.5 | 178.2 | 176.8 | PH6501 | 20001015 | — |
| K75-175/1 | 175 | 180 | 15 | 14.8 | 178.2 | 176.8 | PH6501 | 20001016 | — |
| K75-175/3 | 175 | 180 | 5.6 | 5.4 | 178.2 | 176.8 | PH6501 | 20001018 | — |
| K75-178 | 178 | 186 | 20 | 19.8 | 183 | 181 | PH6501 | 20001019 | — |
| K75-178/1 | 178 | 186 | 9.7 | 9.5 | 183 | 181 | PH6501 | 20001020 | — |
| K75-180 | 180 | 185 | 15 | 14.8 | 183.2 | 181.8 | PH6501 | 20001021 | — |
| K75-180/1 | 180 | 188 | 25 | 24.8 | 185 | 183 | PH6501 | 20001022 | — |
| K75-180/2 | 180 | 185 | 20 | 19.8 | 183.2 | 181.8 | PH6501 | 20001023 | — |
| K75-182 | 182 | 190 | 25 | 24.8 | 187 | 185 | PH6501 | 20001024 | — |
| K75-185 | 185 | 190 | 9.7 | 9.5 | 188.2 | 186.8 | PH6501 | 20001025 | — |
| K75-185/1 | 185 | 190 | 15 | 14.8 | 188.2 | 186.8 | PH6501 | 20001026 | — |
| K75-185/2 | 185 | 193 | 25 | 24.8 | 190 | 188 | PH6501 | 20001027 | — |
| K75-192 | 192 | 200 | 25 | 24.8 | 197 | 195 | PH6501 | 20001028 | — |
| K75-192/1 | 192 | 197 | 15 | 14.8 | 195.2 | 193.8 | PH6501 | 20001029 | — |
| K75-195 | 195 | 200 | 9.7 | 9.5 | 198.2 | 196.8 | PH6501 | 20001031 | — |
| K75-195/1 | 195 | 200 | 15 | 14.8 | 198.2 | 196.8 | PH6501 | 20001032 | — |
| K75-195/3 | 195 | 200 | 25 | 24.8 | 198.2 | 196.8 | PH6501 | 20001034 | — |
| K75-200 | 200 | 205 | 15 | 14.8 | 203.2 | 201.8 | PH6501 | 20001035 | — |
| K75-200/1 | 200 | 208 | 25 | 24.8 | 205 | 203 | PH6501 | 20001036 | — |
| K75-205 | 205 | 210 | 25 | 24.8 | 208.2 | 206.8 | PH6501 | 20001037 | — |
| K75-205/1 | 205 | 210 | 9.7 | 9.5 | 208.2 | 206.8 | PH6501 | 20001038 | — |
| K75-210 | 210 | 218 | 25 | 24.8 | 215 | 213 | PH6501 | 20001039 | — |
| K75-212 | 212 | 220 | 25 | 24.8 | 217 | 215 | PH6501 | 20001040 | — |
| K75-215 | 215 | 220 | 15 | 14.8 | 218.2 | 216.8 | PH6501 | 20001041 | — |
| K75-217 | 217 | 225 | 25 | 24.8 | 222 | 220 | PH6501 | 20001042 | — |
| K75-225 | 225 | 230 | 15 | 14.8 | 228.2 | 226.8 | PH6501 | 20001043 | — |
| K75-235 | 235 | 240 | 25 | 24.8 | 238.2 | 236.8 | PH6501 | 20001045 | — |
| K75-240 | 240 | 245 | 15 | 14.8 | 243.2 | 241.8 | PH6501 | 20001046 | — |
| K75-240/1 | 240 | 248 | 25 | 24.8 | 245 | 243 | PH6501 | 20001047 | — |
| K75-242 | 242 | 250 | 25 | 24.8 | 247 | 245 | PH6501 | 20001048 | — |
| K75-245 | 245 | 250 | 9.7 | 9.5 | 248.2 | 246.8 | PH6501 | 20001049 | — |
| K75-245/1 | 245 | 250 | 15 | 14.8 | 248.2 | 246.8 | PH6501 | 20001050 | — |
| K75-245/2 | 245 | 250 | 25 | 24.8 | 248.2 | 246.8 | PH6501 | 20001051 | — |
| K75-250 | 250 | 258 | 25 | 24.8 | 255 | 253 | PH6501 | 20001052 | — |
| K75-260 | 260 | 268 | 25 | 24.8 | 265 | 263 | PH6501 | 20001053 | — |
| K75-260/1 | 260 | 265 | 25 | 24.8 | 263.2 | 261.8 | PH6501 | 20001054 | — |
| K75-265 | 265 | 270 | 15 | 14.8 | 268.2 | 266.8 | PH6501 | 20001055 | — |
| K75-275 | 275 | 280 | 9.7 | 9.5 | 278.2 | 276.8 | PH6501 | 20001056 | — |
| K75-275/1 | 275 | 280 | 25 | 24.8 | 278.2 | 276.8 | PH6501 | 20001057 | — |
| K75-285 | 285 | 290 | 25 | 24.8 | 288.2 | 286.8 | PH6501 | 20001058 | — |
| K75-290 | 290 | 298 | 25 | 24.8 | 295 | 293 | PH6501 | 20001059 | — |
| K75-292 | 292 | 300 | 25 | 24.8 | 297 | 295 | PH6501 | 20001060 | — |
| K75-295 | 295 | 300 | 15 | 14.8 | 298.2 | 296.8 | PH6501 | 20001061 | — |
| K75-300 | 300 | 308 | 25 | 24.8 | 305 | 303 | PH6501 | 20001062 | — |
| K75-342 | 342 | 350 | 25 | 24.8 | 347 | 345 | PH6501 | 20001065 | — |
| K75-345 | 345 | 350 | 25 | 24.8 | 348.2 | 346.8 | PH6501 | 20001066 | — |
| K75-345/1 | 345 | 350 | 15 | 14.8 | 348.2 | 346.8 | PH6501 | 20001067 | — |
| K75-360 | 360 | 365 | 25 | 24.8 | 363.2 | 361.8 | PH6501 | 20001068 | — |
| K75-392 | 392 | 400 | 25 | 24.8 | 397 | 395 | PH6501 | 20001069 | — |
